FCC ID PD5-WAP361
Wireless-AC/N Dual Radio Wall Plate Access Point with PoE
by Delta Networks, Inc.
Grantee Code: PD5 Product Code: WAP361
Latest application date: 2016-01-29
Device Images
FCC ID Device Details
| FCC ID | PD5-WAP361 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PD5 |
| Product Code | WAP361 |
| Applicant Business | Delta Networks, Inc. 🇹🇼 |
| Related Domains |  delta.com.tw |
| Equipment Class | Wireless-AC/N Dual Radio Wall Plate Access Point with PoE |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2412-2462 MHz | Original Equipment | 2016-01-29 |
| 5180-5240 MHz | Original Equipment | 2016-01-29 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-01-29 | PDF 397.9 KB |
| User Manual (Statement) | Users Manual | 2016-01-29 | PDF 13.1 KB |
| User Manual (statement) | Users Manual | 2016-01-29 | PDF 13.1 KB |
| Internal Photos | Internal Photos | 2016-01-29 | PDF 5 MB |
| External Photos | External Photos | 2016-01-29 | PDF 1.9 MB |
| Label Location | ID Label/Location Info | 2016-01-29 | PDF 33.4 KB |
| Label Sample 1 | ID Label/Location Info | 2016-01-29 | PDF 125 KB |
| Label Sample 2 | ID Label/Location Info | 2016-01-29 | PDF 227.3 KB |
| Test Setup Photos | Test Setup Photos | 2016-01-29 | PDF 558.2 KB |
| Test Report DFS | Test Report | 2016-01-29 | PDF 2.8 MB |
| Test Report DTS | Test Report | 2016-01-29 | PDF 1.9 MB |
| Test Report NII | Test Report | 2016-01-29 | PDF 693.2 KB |
| Attestation (Channel and Mode Declaration) | Cover Letter(s) | 2016-01-29 | PDF 46.8 KB |
| Attestation (DFS Master Declaration) | Cover Letter(s) | 2016-01-29 | PDF 51.8 KB |
| Agent Authorization Letter | Cover Letter(s) | 2016-01-29 | PDF 66.3 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2016-01-29 | PDF 75.1 KB |
| RF Exposure | RF Exposure Info | 2016-01-29 | PDF 58.9 KB |
Application Information
| Application ID | h8pegLDV3Y+P5IKBQWhF/w== |
|---|---|
| Final Action Date | 2016-01-29 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0005865399 |
| Model | -WAP361 |
| Frequency Range | 2412-2462 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Wireless-AC/N Dual Radio Wall Plate Access Point with PoE |
| Responsible Party | Alex Shen, QE Manager, alex.shen@delta.com.tw , 886-3-3591958 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, tommy.wu@tw.bureauveritas.com  , 886-3-3183232 |
| TCB Email | TEI@TIMCOENGR.COM  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures and as evaluated in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| h8pegLDV3Y+P5IKBQWhF/w== | 2016-01-29 | Original Equipment |
| aoRCGyOIVGAWYbE9FwWbLg== | 2016-01-29 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application h8pegLDV3Y+P5IKBQWhF/w==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Timco Engineering, Inc. 849 NW State Road 45 <BR>P.O. Box 370, Newberry, FL 32669 |
Date of Grant: 01/29/2016 Application Dated: 10/29/2015 |
| Delta Networks, Inc. |
| No. 252, Shang Ying Rd., |
| Kuei San District, Taoyuan City 33341, Taiwan |
| Attention: Alex Shen , QE Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PD5-WAP361 |
| Name of Grantee: | Delta Networks, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless-AC/N Dual Radio Wall Plate Access Point with PoE |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.366 |
| Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures and as evaluated in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application h8pegLDV3Y+P5IKBQWhF/w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Delta Networks, Inc. No. 252, Shang Ying Rd., Kuei San District, Taoyuan City 33341, Taiwan |
Date of Grant: 01/29/2016 Application Dated: 10/29/2015 |
| Attention: Alex Shen , QE Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PD5-WAP361 |
| Name of Grantee: | Delta Networks, Inc. |
| Equipment Class: | Digital Transmission System |
| Notes: | Wireless-AC/N Dual Radio Wall Plate Access Point with PoE |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.366 |
| Power listed is maximum combined output power conducted. Device operates with specific antennas in MIMO configurations as described in this filing. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter, except in accordance with FCC multi-transmitter product procedures and as evaluated in this filing. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. This device has a 20 MHz and 40 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
