NWA1050 Outdoor Wireless AP Test Setup Photos - FCC ID PD5-NWA1050

FCC ID PD5-NWA1050

Test setup photos

Outdoor Wireless AP

by Delta Electronics, Inc.

Document preview loads when visible.

Document Details

FCC IDPD5-NWA1050
Document ID6398015
Document TypeTest Setup Photos
DescriptionTest setup photos
Document TitleBAPP-WTW-P22110606_TSup (TSup photo)
ApplicantDelta Electronics, Inc.
Equipment ClassOutdoor Wireless AP
Product CodeNWA1050
Application IDKnc40tpX6ALQdHE5o7uPhA==
Application PurposeOriginal Equipment
Application Date2023-03-09
Frequency Range5180-5240 MHz
FRN0029041993
Test FirmBureau Veritas CPS(H.K.) Ltd., Taoyuan Branch
Certified ByEmerald Chen Specialist
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date09/05/2023
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2023-03-08
Available2023-09-05
Created2023-02-13
Modified2023-02-13
Pages6
File TypeAdobe Acrobat PDF
File Size454889
File SHA-256cb96abf693a419290281a339cb516b35304115ef9a338bf424ebfd444d45b2d0
PDF Metadata Authorpochien
PDF Metadata Producerpochien Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 6398015, FCC.gov 6397952
