3165NG Wireless Network Adapter Test Setup Photos - FCC ID PD93165NG

FCC ID PD93165NG

Test Setup Photos UNII

Wireless Network Adapter

by Intel Corporation

Document preview loads when visible.

Document Details

FCC IDPD93165NG
Document ID2512825
Document TypeTest Setup Photos
DescriptionTest Setup Photos UNII
Document Title44948RRE003_Photographs
ApplicantIntel Corporation
Equipment ClassWireless Network Adapter
Product Code3165NG
Application IDUzWDB0gSvKy0M9icofVlAQ==
Application PurposeOriginal Equipment
Application Date2015-01-23
Frequency Range5180-5240 MHz
FRN0008035131
Test FirmDEKRA Testing and Certification, S.A.U.
Certified BySteven C. Hackett
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/21/2015
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2015-01-23
Available2015-07-21
Created2015-01-21
Modified2015-01-21
Pages4
File TypeAdobe Acrobat PDF
File Size4264358
File SHA-256e2be55d7d5f756a4c1ea5bc48d115ad65a56091b3b552b64b42bbd2e874f1991
PDF Metadata AuthorALL
PDF Metadata ProducerGPL Ghostscript 9.04 ALL
FCC.gov SourcesFCC.gov 2512825
