512ANXMU Intel Wi-Fi/WiMax Link 5150... - FCC ID PD9512ANXMU

FCC ID PD9512ANXMU

Internal Photos

Intel Wi-Fi/WiMax Link 5150

by Intel Mobile Communications

Document preview loads when visible.

Document Details

FCC IDPD9512ANXMU
Document ID1024707
Document TypeInternal Photos
DescriptionInternal Photos
Document TitlePhotographs - Internal
ApplicantIntel Mobile Communications
Equipment ClassIntel Wi-Fi/WiMax Link 5150
Product Code512ANXMU
Application IDd0g+pVEQ+VfOwLK/d7LT/w==
Application PurposeOriginal Equipment
Application Date2008-11-03
Frequency Range2496-2690 MHz
FRN0008035131
Test FirmAEGIS Labs, Inc.
Certified ByRobert W. Paxman
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2008-10-31
Available2008-11-03
Created2008-09-05
Modified2008-09-05
Pages4
File TypeAdobe Acrobat PDF
File Size1733553
File SHA-256d6989abbe5e2bfc9feb263f9c537923b7d51153d4cbbb64551090fc61e97ff4b
PDF Metadata AuthorKevin
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 1024707, FCC.gov 1024690, FCC.gov 1024669, FCC.gov 1024626
