AX204D2 Intel Wi-Fi 6E AX204 Test Report - FCC ID PD9AX204D2

FCC ID PD9AX204D2

Test Report DTS Part 1

Intel Wi-Fi 6E AX204

by Intel Corporation

Document preview loads when visible.

Document Details

FCC IDPD9AX204D2
Document ID5855469
Document TypeTest Report
DescriptionTest Report DTS Part 1
Document Title220225-03.TR04
ApplicantIntel Corporation
Equipment ClassIntel Wi-Fi 6E AX204
Product CodeAX204D2
Application ID/vjWokiRrtj8nx5ZLDxu/w==
Application PurposeOriginal Equipment
Application Date2022-05-02
Frequency Range2402-2480 MHz
FRN0008035131
Test FirmIntel Corporation S.A.S.
Certified BySteven C. Hackett Regulatory Certification Director Intel Corp.
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/27/2022
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2022-04-30
Available2022-05-02
Created2022-04-13
Modified2022-04-13
Pages56
File TypeAdobe Acrobat PDF
File Size4080509
File SHA-256184691fdc8b1ba7f1deb271fc8abdaf79b65f5b615db2cd515d2f564c7c2d6da
PDF Metadata AuthorDesblancs, Claire
PDF Metadata ProducerDesblancs, Claire Microsoft® Word for Microsoft 365
FCC.gov SourcesFCC.gov 5855469
