GMRS500SLK GMRS/FRS Combination Block Diagram - FCC ID PDHGMRS500SLK

FCC ID PDHGMRS500SLK

Block Diagram

GMRS/FRS Combination

by TTI Tech Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDPDHGMRS500SLK
Document ID412579
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleCAM output
ApplicantTTI Tech Co., Ltd.
Equipment ClassGMRS/FRS Combination
Product CodeGMRS500SLK
Application IDL3xPW9yLCECirrpKN9y6zg==
Application PurposeOriginal Equipment
Application Date2004-04-07
Frequency Range462.55-462.725 MHz
FRN0017823113
Test FirmThru Lab & Engineering
Certified ByH.J. Lee Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-04-07
Available2004-04-07
Created2004-03-26
Modified2004-03-26
Pages1
File TypeAdobe Acrobat PDF
File Size33726
File SHA-2567481f44352ecaee3013d5aaf2a691cac60e880ce99a01c0f9714cefcbc8462a2
PDF Metadata Authorrdpcb1
PDF Metadata ProducerAcrobat Distiller 5.0 (Windows) rdpcb1
FCC.gov SourcesFCC.gov 412579, FCC.gov 640581
