IP240R Wireless Mouse Receiver External Photos - FCC ID PE3IP-240R

FCC ID PE3IP-240R

EXTERNAL PHOTOS

Wireless Mouse Receiver

by ISV Co., Ltd.

Document preview loads when visible.

Document Details

FCC IDPE3IP-240R
Document ID366681
Document TypeExternal Photos
DescriptionEXTERNAL PHOTOS
ApplicantISV Co., Ltd.
Equipment ClassWireless Mouse Receiver
Product CodeIP240R
Application IDRO12Rw8CHvHOOZrX829oNw==
Application PurposeOriginal Equipment
Application Date2003-10-17
FRN0006172266
Test FirmThru Lab & Engineering
Certified ByMu-Hyun Kim
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-10-21
Available2003-10-17
Created2003-10-15
Modified2003-10-15
Pages1
File TypeAdobe Acrobat PDF
File Size187358
File SHA-256c4910a86ba94d5e42e6d7e61a1afabcd2b2d0804771a70f4acafff49aa3bd740
PDF Metadata ProducerAcrobat Distiller 4.0 for Windows
FCC.gov SourcesFCC.gov 366681
