931040804 433MHz RF Transmitter... - FCC ID PEQ931040804

FCC ID PEQ931040804

Technical Description

433MHz RF Transmitter

by Electronics Tomorrow Ltd.

Document preview loads when visible.

Document Details

FCC IDPEQ931040804
Document ID472216
Document TypeOperational Description
DescriptionTechnical Description
Document Title9310 block diagram
ApplicantElectronics Tomorrow Ltd.
Equipment Class433MHz RF Transmitter
Product Code931040804
Application IDN/LoC0QYpkKNrnGcSsEOYA==
Application PurposeOriginal Equipment
Application Date2004-09-24
Frequency Range433.95 MHz
FRN0018426122
Test FirmIntertek Testing Services Hong Kong
Certified ByDerek Leung Assistant Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2004-09-24
Available2004-09-24
Created2004-09-07
Modified2004-09-07
Pages1
File TypeAdobe Acrobat PDF
File Size55229
File SHA-256b2685cb4ef99d722549bf9ab76fb8e26a991053d98fcaa5e8d7301e06c0c1f62
PDF Metadata Authorcho
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows) cho
FCC.gov SourcesFCC.gov 472216
