C61W ARRIS C61W-700 Wireless RVU Client Test... - FCC ID PGRC61W
FCC ID PGRC61W
Test Photos
ARRIS C61W-700 Wireless RVU Client
by ARRIS
Document preview loads when visible.
Document Details
| FCC ID | PGRC61W |
|---|---|
| Document ID | 3386631 |
| Document Type | Test Setup Photos |
| Description | Test Photos |
| Document Title | Test Configuration Photographsx |
| Applicant | ARRIS |
| Equipment Class | ARRIS C61W-700 Wireless RVU Client |
| Product Code | C61W |
| Application ID | islyptJzP+Agu42yQRtg7w== |
| Application Purpose | Original Equipment |
| Application Date | 2017-05-19 |
| Frequency Range | 5180-5240 MHz |
| FRN | 0017832825 |
| Test Firm | National Technical Systems |
| Certified By | Mark Hill Staff Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 11/06/2017 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2017-05-10 |
| Available | 2017-11-06 |
| Created | 2017-04-25 |
| Modified | 2017-04-25 |
| Pages | 6 |
| File Type | Adobe Acrobat PDF |
| File Size | 2684418 |
| File SHA-256 | a7e1215aff596ee161eb7295fa5bf57172b0710af1f0a93d31f2eac8b30f2cbe |
| PDF Metadata Author | dguidotti |
| PDF Metadata Producer | Acrobat Distiller 11.0 (Windows) dguidotti |
| FCC.gov Sources | FCC.gov 3386631, FCC.gov 3386573 |
