DJAXD4 UHF DIGITAL TRANSCEIVER External Photos - FCC ID PH3DJ-AXD4
FCC ID PH3DJ-AXD4
External Photos
UHF DIGITAL TRANSCEIVER
Document preview loads when visible.
Document Details
| FCC ID | PH3DJ-AXD4 |
|---|---|
| Document ID | 3306141 |
| Document Type | External Photos |
| Description | External Photos |
| Document Title | DJ-AXD4_External Photos |
| Applicant | Alinco Incorporated, Electronics Division |
| Equipment Class | UHF DIGITAL TRANSCEIVER |
| Product Code | DJAXD4 |
| Application ID | HhNWaOdMvv6Z6INxRWtiRA== |
| Application Purpose | Original Equipment |
| Application Date | 2017-03-07 |
| Frequency Range | 406.1-470 MHz |
| FRN | 0022821441 |
| Test Firm | Most Technology Service Co., Ltd. |
| Certified By | Kazuhiro Kusuhara General Manager, Production, Electronics Div. |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2017-03-07 |
| Available | 2017-03-07 |
| Created | 2017-02-23 |
| Modified | 2017-02-23 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 272538 |
| File SHA-256 | 8d1dd62892e603755d81b964fb949608e5fa0e53ccca08675ae01d851011663e |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Acrobat Elements 7.0.5 (Windows) Administrator |
| FCC.gov Sources | FCC.gov 3306141 |
