MMDSCPE5 Non-Line of Site Wireless Data... - FCC ID PHX-MMDS-CPE5

FCC ID PHX-MMDS-CPE5

Internal photos

Non-Line of Site Wireless Data Link

by Nokia Solutions and Networks

Document preview loads when visible.

Document Details

FCC IDPHX-MMDS-CPE5
Document ID383843
Document TypeInternal Photos
DescriptionInternal photos
Document TitleExhibit 9 Internal Photographs
ApplicantNokia Solutions and Networks
Equipment ClassNon-Line of Site Wireless Data Link
Product CodeMMDSCPE5
Application IDnTzZpmfJMUnyJw8WhlFlhw==
Application PurposeOriginal Equipment
Application Date2003-12-22
Frequency Range2500-2686 MHz
FRN0016412652
Certified ByTim Blom Principal Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-12-22
Available2003-12-22
Created2003-12-05
Modified2003-12-05
Pages10
File TypeAdobe Acrobat PDF
File Size1123347
File SHA-25656bb9681a6fecda6d816905abaff590e88baabaca498591d168dadbf55d477d7
PDF Metadata Authorchester-jonesa
PDF Metadata ProducerExhibit 9 Internal Photographs.doc - Microsoft Word Acrobat PDFWriter 5.0 for Windows NT
FCC.gov SourcesFCC.gov 383843
