MMAX2310L WiMAX base station Teardown... - FCC ID PIDMMAX2310L

FCC ID PIDMMAX2310L

Internal photos

WiMAX base station

by Airspan Networks Inc

Document preview loads when visible.

Document Details

FCC IDPIDMMAX2310L
Document ID1481698
Document TypeInternal Photos
DescriptionInternal photos
Document TitleInternal_photos_22030
ApplicantAirspan Networks Inc
Equipment ClassWiMAX base station
Product CodeMMAX2310L
Application IDLJbQrvB72enxihcfHPfVtw==
Application PurposeOriginal Equipment
Application Date2011-07-07
Frequency Range2316.75 MHz
FRN0009320326
Test FirmHermon Laboratories Ltd.
Certified ByZion Levi Compliances & Integration Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/01/2011
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2011-06-13
Available2011-12-01
Created2011-06-13
Modified2011-06-13
Pages10
File TypeAdobe Acrobat PDF
File Size970023
File SHA-25692ea24c5148d9644df8be7acedeaad4992e2f8d68965ed2ddcdca1f1dfaec2b3
PDF Metadata Authormarina
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 10.0.0 (Windows)
FCC.gov SourcesFCC.gov 1481698
