FCC ID PIYFBL83-16A5R
HOTWHEELS Ai INTELLIENT RACE SYSTEM-CAR (2.4GHz TRANSCEIVER)
by Mattel Asia Pacific Sourcing Ltd.
Grantee Code: PIY Product Code: FBL8316A5R
Latest application date: 2016-11-29
Device Images
FCC ID Device Details
| FCC ID | PIYFBL83-16A5R |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PIY |
| Product Code | FBL8316A5R |
| Applicant Business | Mattel Asia Pacific Sourcing Ltd. |
| Related Domains |  mattel.com |
| Equipment Class | HOTWHEELS Ai INTELLIENT RACE SYSTEM-CAR (2.4GHz TRANSCEIVER) |
| Test Firm | SGS IECC Limited |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2405-2463 MHz | Original Equipment | 2016-11-29 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual_PIYFBL83-16A5R_4390C-FBL8316A5R | Users Manual | 2016-11-29 | PDF 3.4 MB |
| Internal Photo_PIYFBL83-16A5R_4390C-FBL8316A5R_rev1 | Internal Photos | 2016-11-29 | PDF 2.2 MB |
| External Photo_PIYFBL83-16A5R_4390C-FBL8316A5R | External Photos | 2016-11-29 | PDF 842.3 KB |
| label_PIYFBL83-16A5R_4390C-FBL8316A5R_rev1 | ID Label/Location Info | 2016-11-29 | PDF 424 KB |
| Setup Photo_PIYFBL83-16A5T_4930C-FBL8316A5R | Test Setup Photos | 2016-11-29 | PDF 549.1 KB |
| report_PIYFBL83-16A5R_rev1 | Test Report | 2016-11-29 | PDF 640.6 KB |
| FCC Authority to Act as Agent_PIYFBL83-16A5R | Cover Letter(s) | 2016-11-29 | PDF 54.9 KB |
| FCC Request for Confidentiality_PIYFBL83-16A5R | Cover Letter(s) | 2016-11-29 | PDF 71.9 KB |
| Confidential_Block Diagram_PIYFBL83_16A5R_4390C-FBL8316A5R_rev1 Metadata only | Block Diagram | PDF 356.1 KB | |
| Confidential_circuit diagram_PIYFBL83_16A5R_4390C-FBL8316A5R_rev2 Metadata only | Schematics | PDF 422.2 KB | |
| Confidential_operation description_PIYFBL83-16A5R_4390C-FBL8316A5R_rev1 Metadata only | Operational Description | PDF 1.7 MB |
Application Information
| Application ID | tENi3QMPXWIdfC3f1+VZiA== |
|---|---|
| Final Action Date | 2016-11-29 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0009479130 |
| Model | FBL83-16A5R |
| Frequency Range | 2405-2463 MHz |
| Equipment Class | DXT - Part 15 Low Power Transceiver, Rx Verified |
| Device Description | HOTWHEELS Ai INTELLIENT RACE SYSTEM-CAR (2.4GHz TRANSCEIVER) |
| Responsible Party | Joule Mak, Director, Electronic Engineering, Joule.Mak@mattel.com , 31855000 |
| Technical Contact | Jeffrey Chen, SGS IECC Limited, Jeffrey.Chen@sgs.com  , 85223052570 |
| Test Firm | Jeffrey Chen, SGS IECC Limited, Jeffrey.Chen@sgs.com , 85227747413 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| tENi3QMPXWIdfC3f1+VZiA== | 2016-11-29 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2405-2463 MHz | 15C |
Grants
TCB Grant - Application tENi3QMPXWIdfC3f1+VZiA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 11/29/2016 Application Dated: 11/27/2016 |
| Mattel Asia Pacific Sourcing Ltd. |
| 13/F., South Tower, World Finance Centre, |
| Harbour City, Tsimshatsui, |
| Kowloon, 852 Hong Kong |
| Attention: Joule Mak , Director, Electronic Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PIYFBL83-16A5R |
| Name of Grantee: | Mattel Asia Pacific Sourcing Ltd. |
| Equipment Class: | Part 15 Low Power Transceiver, Rx Verified |
| Notes: | HOTWHEELS Ai INTELLIENT RACE SYSTEM-CAR (2.4GHz TRANSCEIVER) |
