SV01TX Video/ Audio Wireless TX External Photos - FCC ID PJDSV-01-TX

FCC ID PJDSV-01-TX

external rear

Video/ Audio Wireless TX

by Strategic Vista (BVI) Ltd.

external rear

Document Details

FCC IDPJDSV-01-TX
Document ID148135
Document TypeExternal Photos
Descriptionexternal rear
ApplicantStrategic Vista (BVI) Ltd.
Equipment ClassVideo/ Audio Wireless TX
Product CodeSV01TX
Application IDfUrlY4KKo928x/2xVTpVxQ==
Application PurposeOriginal Equipment
Application Date2001-04-17
Frequency Range2410.5-2472.5 MHz
FRN0006763619
Test FirmTimco Engineering, Inc.
Certified ByJoel Kligman President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-05-07
Available2001-04-17
Pages0
File TypeJPEG Image
File Size49035
File SHA-256fe501d977d7466d6fab38bc7e1d0922b407de3e2b1abbacf346ae2e683cf0bfc
FCC.gov SourcesFCC.gov 148135
