FCC ID PJZ2728Y1
GPON 4 Port WiFi 802.11ac Gateway, GE 4 Port WiFi 802.11ac Gateway
by DASAN Zhone Solutions, Inc.
Grantee Code: PJZ Product Code: 2728Y1
Latest application date: 2016-08-08
Device Images
FCC ID Device Details
| FCC ID | PJZ2728Y1 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PJZ |
| Product Code | 2728Y1 |
| Applicant Business | DASAN Zhone Solutions, Inc. 🇺🇸 |
| Related Domains |  dasanzhone.com  newbtl.com |
| Equipment Class | GPON 4 Port WiFi 802.11ac Gateway, GE 4 Port WiFi 802.11ac Gateway |
| Test Firm | BTL Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-08-08 |
| 2412-2462 MHz | Original Equipment | 2016-08-08 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-08-08 | PDF 858.4 KB |
| Internal Photos | Internal Photos | 2016-08-08 | PDF 2.4 MB |
| External Photos | External Photos | 2016-08-08 | PDF 827.8 KB |
| ID Label/Location Info | ID Label/Location Info | 2016-08-08 | PDF 569.9 KB |
| Test Setup Photos | Test Setup Photos | 2016-08-08 | PDF 393.3 KB |
| Test Report | Test Report | 2016-08-08 | PDF 3.5 MB |
| Test Report-5G_Part 1 | Test Report | 2016-08-08 | PDF 4.9 MB |
| Test Report-5G_Part 2 | Test Report | 2016-08-08 | PDF 4.9 MB |
| Test Report-5G_Part 3 | Test Report | 2016-08-08 | PDF 4.8 MB |
| Declaration of authorization | Cover Letter(s) | 2016-08-08 | PDF 28.1 KB |
| FCC DOC | Cover Letter(s) | 2016-08-08 | PDF 537.8 KB |
| Request for non-disclosure | Cover Letter(s) | 2016-08-08 | PDF 32.6 KB |
| FCC RF Exposure Info | RF Exposure Info | 2016-08-08 | PDF 127 KB |
| MPE | RF Exposure Info | 2016-08-08 | PDF 127 KB |
| Block Diagram Metadata only | Block Diagram | PDF 106.7 KB | |
| Schematics Metadata only | Schematics | PDF 918.2 KB | |
| Operational Description Metadata only | Operational Description | PDF 77.7 KB | |
| software security Metadata only | Operational Description | PDF 61.7 KB |
Application Information
| Application ID | o5lvMZuXfb/4a3eznyTtiw== |
|---|---|
| Final Action Date | 2016-08-08 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0004367017 |
| Model | 2728Y1 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | GPON 4 Port WiFi 802.11ac Gateway, GE 4 Port WiFi 802.11ac Gateway |
| Responsible Party | Keith Nauman, SVP, Global Quality & Service, KNauman@dasanzhone.com , 510-777-7000 |
| Agent | Cathy Cathy Cathy, BTL Inc., cathy@newbtl.com , 86-769-83183000 |
| Technical Contact | Steven Lu, BTL Inc., steven@newbtl.com , 86-769-83183000 |
| Non-Technical Contact | Cathy Wang, BTL Inc., cathy@newbtl.com , 86-769-83183000 |
| Test Firm | Daisy Dai, BTL Inc., daisy.dai@btl.org.cn  , 008676983183000 |
| TCB Email | certification@telefication.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users and installers must be provided with antenna installation and transmitter operating conditions for satisfying RF exposure compliance. This device has 20/40/80 MHz bandwidth modes. The 80 MHz mode is limited to channel at 5210 MHz and 5775 MHz. |
