RF900 Low Power RF Transceiver Block Diagram - FCC ID PMPRF900

FCC ID PMPRF900

Exhibit B Block Diagram per 2 1033 b5

Low Power RF Transceiver

by Digi-Star LLC

Document preview loads when visible.

Document Details

FCC IDPMPRF900
Document ID173737
Document TypeBlock Diagram
DescriptionExhibit B Block Diagram per 2 1033 b5
Document Title[Sheet1]
ApplicantDigi-Star LLC
Equipment ClassLow Power RF Transceiver
Product CodeRF900
Application IDBxl+bZTuvvNI1pcOcGYCwQ==
Application PurposeOriginal Equipment
Application Date2001-10-10
Frequency Range903-918 MHz
FRN9999999999
Test FirmRetlif Testing Laboratories
Certified ByBruce Johnston Director of Engineering
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2001-10-10
Available2001-10-10
Created2001-05-02
Modified2001-05-02
Pages1
File TypeAdobe Acrobat PDF
File Size28924
File SHA-256aa9af9daa1ee3f5cc954abf15eacfe54c3072c72e0a3877d1cea92abfefb70eb
PDF Metadata Authorjim
PDF Metadata ProducerAccelEDA Acrobat PDFWriter 4.0 for Windows
FCC.gov SourcesFCC.gov 173737
