RC2793259A RC Car Block Diagram - FCC ID PN6RC2793259A

FCC ID PN6RC2793259A

Block Diagram

RC Car

by Maison Joseph Battat Ltd.

Document preview loads when visible.

Document Details

FCC IDPN6RC2793259A
Document ID592334
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantMaison Joseph Battat Ltd.
Equipment ClassRC Car
Product CodeRC2793259A
Application IDTOWsTAepgQN58y0vAc765A==
Application PurposeOriginal Equipment
Application Date2005-10-17
Frequency Range27.145 MHz
FRN0003786449
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-10-17
Available2005-10-17
Created2005-10-04
Modified2005-10-04
Pages1
File TypeAdobe Acrobat PDF
File Size16964
File SHA-25638fcfe342ec2b0be40974cfad90f6860120a23c7e48ea6a6ff2adace5ec7a61c
PDF Metadata AuthorITS ELECTRIC TOY
PDF Metadata ProducerITS ELECTRIC TOY
FCC.gov SourcesFCC.gov 592334
