4XX Remote Control Transmitter Schematics - FCC ID PNZ4XX
FCC ID PNZ4XX
schematics
Remote Control Transmitter
by Xilor Inc
Document preview loads when visible.
Document Details
| FCC ID | PNZ4XX |
|---|---|
| Document ID | 166552 |
| Document Type | Schematics |
| Description | schematics |
| Document Title | Protel Schematic |
| Applicant | Xilor Inc |
| Equipment Class | Remote Control Transmitter |
| Product Code | 4XX |
| Application ID | JP9b5HGiIsG+aXg+ti7sLQ== |
| Application Purpose | Original Equipment |
| Application Date | 2001-08-24 |
| Frequency Range | 418 MHz |
| FRN | 0004383972 |
| Test Firm | Global Testing Laboratory, LLC |
| Certified By | Brian Miller Compliance Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2001-08-27 |
| Available | 2001-08-24 |
| Created | 2001-08-23 |
| Modified | 2001-08-23 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 18328 |
| File SHA-256 | b8f8612a2381fb536f6cec0488cda618281f3c15fa6de083286f0405f1e1cfb2 |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Design Explorer Acrobat PDFWriter 4.0 for Windows NT |
| FCC.gov Sources | FCC.gov 166552 |
