FCC ID POE-WF003
Stream 3
by Strax Asia Limited
Grantee Code: POE Product Code: WF003
Latest application date: 2016-06-15
Device Images
FCC ID Device Details
| FCC ID | POE-WF003 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | POE |
| Product Code | WF003 |
| Applicant Business | Strax Asia Limited |
| Related Domains |  strax.com.hk |
| Equipment Class | Stream 3 |
| Test Firm | Most Technology Service Co., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-06-15 |
| 2412-2462 MHz | Original Equipment | 2016-06-15 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User manual | Users Manual | 2016-06-15 | PDF 5.9 MB |
| Internal Photo | Internal Photos | 2016-06-15 | PDF 1,016.1 KB |
| External Photos | External Photos | 2016-06-15 | PDF 418.3 KB |
| Label& label location | ID Label/Location Info | 2016-06-15 | PDF 317.8 KB |
| Test Setup Photo | Test Setup Photos | 2016-06-15 | PDF 241.4 KB |
| Test Report | Test Report | 2016-06-15 | PDF 1.3 MB |
| Test Report | Test Report | 2016-06-15 | PDF 1.5 MB |
| Agent Authorization Letter | Cover Letter(s) | 2016-06-15 | PDF 16.8 KB |
| Declaration statement Letter | Cover Letter(s) | 2016-06-15 | PDF 14.5 KB |
| Long Term Confidentiality Request Letter | Cover Letter(s) | 2016-06-15 | PDF 17.1 KB |
| Model difference letter | Cover Letter(s) | 2016-06-15 | PDF 25.4 KB |
| BT Module Block diagram Metadata only | Block Diagram | PDF 276.3 KB | |
| Block diagram Metadata only | Block Diagram | PDF 32.9 KB | |
| WIFI Module Block Diagram Metadata only | Block Diagram | PDF 118.4 KB | |
| BT Module SCH Metadata only | Schematics | PDF 55.6 KB | |
| SCH Metadata only | Schematics | PDF 1.1 MB | |
| WIFI Module SCH Metadata only | Schematics | PDF 200.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 47.5 KB | |
| BOM List Metadata only | Parts List/Tune Up Info | PDF 247.8 KB |
Application Information
| Application ID | 8gZRajP3aW6vftiOA7fOcg== |
|---|---|
| Final Action Date | 2016-06-15 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022007231 |
| Model | WF003 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Stream 3 |
| Responsible Party | Howard Leung, General Manager, howard.leung@strax.com.hk , 23990670 |
| Technical Contact | Mark Wen, Most Technology Service Co.,Ltd., szmost@szmost.com  , 86-755-86026850 |
| Test Firm | Mark Wen, Most Technology Service Co., Ltd., szmost@szmost.com , 86-755-86170306 |
| TCB Email | tcbinfo@metlabs.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output Power listed is conducted. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| 8gZRajP3aW6vftiOA7fOcg== | 2016-06-15 | Original Equipment |
| 68vckgmj25Cu9f1CWXYqtA== | 2016-06-15 | Original Equipment |
Grants
TCB Grant - Application 8gZRajP3aW6vftiOA7fOcg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 06/15/2016 Application Dated: 06/15/2016 |
| Strax Asia Limited |
| D2, 1/F, Lucky Horse Industrial Building |
| 64 Tong Mi Road, Mongkok |
| Kowloon, Hong Kong |
| Attention: Howard Leung , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | POE-WF003 |
| Name of Grantee: | Strax Asia Limited |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Stream 3 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.001 |
| Output Power listed is conducted. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
EAS Grant - Application 8gZRajP3aW6vftiOA7fOcg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Strax Asia Limited D2, 1/F, Lucky Horse Industrial Building 64 Tong Mi Road, MongkokP.O. Box , Kowloon, Hong Kong |
Date of Grant: 06/15/2016 Application Dated: 06/15/2016 |
| Attention: Howard Leung , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | POE-WF003 |
| Name of Grantee: | Strax Asia Limited |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Stream 3 |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 | 0.001 |
| Output Power listed is conducted. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Eurofins Electrical and Electronic Testing NA, Inc 914 W. Patapsco Avenue Baltimore, MD 21230-3432 |
Date of Grant: 06/15/2016 Application Dated: 06/15/2016 |
| Strax Asia Limited |
| D2, 1/F, Lucky Horse Industrial Building |
| 64 Tong Mi Road, Mongkok |
| Kowloon, Hong Kong |
| Attention: Howard Leung , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | POE-WF003 |
| Name of Grantee: | Strax Asia Limited |
| Equipment Class: | Digital Transmission System |
| Notes: | Stream 3 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.016 |
| Output power is conducted. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Device supports 20 MHz and 40 MHz bandwidth modes. |
EAS Grant - Application 68vckgmj25Cu9f1CWXYqtA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Strax Asia Limited D2, 1/F, Lucky Horse Industrial Building 64 Tong Mi Road, MongkokP.O. Box , Kowloon, Hong Kong |
Date of Grant: 06/15/2016 Application Dated: 06/15/2016 |
| Attention: Howard Leung , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | POE-WF003 |
| Name of Grantee: | Strax Asia Limited |
| Equipment Class: | Digital Transmission System |
| Notes: | Stream 3 |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2412.0 - 2462.0 | 0.016 |
| Output power is conducted. The antennas used for this transmitter as shown in this filing must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. Device supports 20 MHz and 40 MHz bandwidth modes. |
| Mail To: |
