RM77XH GSM 850/1800/1900 Cellular Telephone... - FCC ID PPIRM-77XH

FCC ID PPIRM-77XH

Internal photos

GSM 850/1800/1900 Cellular Telephone

by Microsoft Corporation

Document preview loads when visible.

Document Details

FCC IDPPIRM-77XH
Document ID566767
Document TypeInternal Photos
DescriptionInternal photos
Document TitleNokia Standard Template
ApplicantMicrosoft Corporation
Equipment ClassGSM 850/1800/1900 Cellular Telephone
Product CodeRM77XH
Application IDpcoh1MW6F40VVhblSeRuYw==
Application PurposeOriginal Equipment
Application Date2005-09-09
Frequency Range1850.2-1909.8 MHz
FRN0007807100
Certified ByThomas Reitmayer Product Certification Manger
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-07-29
Available2005-09-09
Created2005-07-21
Modified2005-07-21
Pages6
File TypeAdobe Acrobat PDF
File Size372918
File SHA-256de0aca00537b04179b27d5a6a273de6b0a1bce7b6677a3bc062b7fdff2c89bb3
PDF Metadata AuthorNokia behrens
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows) behrens
FCC.gov SourcesFCC.gov 566767
