WCBN3509R38 802.11a/b/g/n 2Tx2R USB... - FCC ID PPQ-WCBN3509R38

FCC ID PPQ-WCBN3509R38

Test Setup Photos DFS

802.11a/b/g/n 2Tx2R USB WLAN Module

by LITE-ON TECHNOLOGY CORP.

Document preview loads when visible.

Document Details

FCC IDPPQ-WCBN3509R38
Document ID4570474
Document TypeTest Setup Photos
DescriptionTest Setup Photos DFS
Document Title工事設計書
ApplicantLITE-ON TECHNOLOGY CORP.
Equipment Class802.11a/b/g/n 2Tx2R USB WLAN Module
Product CodeWCBN3509R38
Application IDZNfGQoTuu5GsxI+6E26lHA==
Application PurposeOriginal Equipment
Application Date2019-12-31
Frequency Range5180-5240 MHz
FRN0014765044
Test FirmSporton International Inc.
Certified ByLeo Huang Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/28/2020
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2019-12-30
Available2020-06-28
Created2019-12-16
Modified2019-12-16
Pages1
File TypeAdobe Acrobat PDF
File Size175674
File SHA-25649a4057d48fedb2714ea0ee1c8796fd32cccce012aeef189d9418950e0637b79
PDF Metadata AuthorBunny
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 4570474
