WCBN4501A Wi-Fi (11a/b/g/n/ac 2Tx2R)+BT... - FCC ID PPQ-WCBN4501A

FCC ID PPQ-WCBN4501A

MPE Report

Wi-Fi (11a/b/g/n/ac 2Tx2R)+BT (V4.1LE) USB Combo Module

by LITE-ON TECHNOLOGY CORP.

Document preview loads when visible.

Document Details

FCC IDPPQ-WCBN4501A
Document ID3470863
Document TypeRF Exposure Info
DescriptionMPE Report
ApplicantLITE-ON TECHNOLOGY CORP.
Equipment ClassWi-Fi (11a/b/g/n/ac 2Tx2R)+BT (V4.1LE) USB Combo Module
Product CodeWCBN4501A
Application IDpUu2/2TS8G65irrZFTWSpA==
Application PurposeOriginal Equipment
Application Date2017-07-19
Frequency Range5180-5240 MHz
FRN0014765044
Test FirmCompliance Certification Services Inc.
Certified ByTC Wu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2017-07-19
Available2017-07-19
Created2017-07-18
Modified2017-07-18
Pages8
File TypeAdobe Acrobat PDF
File Size106740
File SHA-256faa67fb384a784ab4efc77d6d342fc07efa410dabcb0cd8122ddb067069ad8f2
PDF Metadata Authorjulia.wei
PDF Metadata Producerjulia.wei Microsoft® Word 2010
FCC.gov SourcesFCC.gov 3470863, FCC.gov 3470785, FCC.gov 3470757
