FCC ID PQC-WLANBV3
WLAN Module IEEE 802.11 a/b/g/n
by Philips Medical Systems North America Co.
Grantee Code: PQC Product Code: WLANBV3
Latest application date: 2017-06-12
Device Images
FCC ID Device Details
| FCC ID | PQC-WLANBV3 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PQC |
| Product Code | WLANBV3 |
| Applicant Business | Philips Medical Systems North America Co. 🇺🇸 |
| Related Domains |  philips.com |
| Equipment Class | WLAN Module IEEE 802.11 a/b/g/n |
| Test Firm | CTC advanced GmbH |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2017-06-12 |
| 2412-2462 MHz | Class II permissive change or modification of presently authorized equipment | 2017-06-12 |
| 5180-5240 MHz | Original Equipment | 2017-05-16 |
| 2412-2462 MHz | Original Equipment | 2017-05-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual 865221 english | Users Manual | 2017-06-12 | PDF 2.4 MB |
| user_manual mp2 english | Users Manual | 2017-06-12 | PDF 2.7 MB |
| User manual | Users Manual | 2017-05-16 | PDF 130.1 KB |
| Internal Photos | Internal Photos | 2017-05-16 | PDF 2.1 MB |
| External Photos | External Photos | 2017-05-16 | PDF 2.2 MB |
| label 865221 | ID Label/Location Info | 2017-06-12 | PDF 431.2 KB |
| label mp2 front | ID Label/Location Info | 2017-06-12 | PDF 90.6 KB |
| label mp2 rear | ID Label/Location Info | 2017-06-12 | PDF 337.6 KB |
| Label | ID Label/Location Info | 2017-05-16 | PDF 141.7 KB |
| Label location | ID Label/Location Info | 2017-05-16 | PDF 39.2 KB |
| TestSetup Photos | Test Setup Photos | 2017-05-16 | PDF 1.7 MB |
| Test Report WLAN 2G4 | Test Report | 2017-05-16 | PDF 4 MB |
| Test Report WLAN 2G4 appendix_part1 | Test Report | 2017-05-16 | PDF 5.9 MB |
| Test Report WLAN 2G4 appendix_part2 | Test Report | 2017-05-16 | PDF 3.6 MB |
| Test Report WLAN 5GHz appendix1 | Test Report | 2017-05-16 | PDF 5.5 MB |
| Test Report WLAN 5GHz appendix2 | Test Report | 2017-05-16 | PDF 5.4 MB |
| Test Report WLAN 5GHz appendix3 | Test Report | 2017-05-16 | PDF 5.5 MB |
| Test Report WLAN 5GHz appendix4 | Test Report | 2017-05-16 | PDF 5.5 MB |
| Test Report WLAN 5GHz appendix5 | Test Report | 2017-05-16 | PDF 5.4 MB |
| Test Report WLAN 5GHz appendix6 | Test Report | 2017-05-16 | PDF 5.4 MB |
| Test Report WLAN 5GHz appendix7 | Test Report | 2017-05-16 | PDF 2.6 MB |
| Test Report WLAN 5GHz part1 | Test Report | 2017-05-16 | PDF 5 MB |
| Test Report WLAN 5GHz part2 | Test Report | 2017-05-16 | PDF 2.5 MB |
| dfs client test report | Test Report | 2017-05-16 | PDF 572.5 KB |
| pc2_pc4 865221 to allow portable configuration 865221 | Cover Letter(s) | 2017-06-12 | PDF 738.1 KB |
| pc2_pc4 MP2 to allow portable configuration mp2 | Cover Letter(s) | 2017-06-12 | PDF 709.8 KB |
| confidentiality request permanent fcc signed | Cover Letter(s) | 2017-05-16 | PDF 602.3 KB |
| declaration for re-use of test data | Cover Letter(s) | 2017-05-16 | PDF 40.9 KB |
| modular approval request fcc signed | Cover Letter(s) | 2017-05-16 | PDF 1.3 MB |
| SAR Report 865221 | RF Exposure Info | 2017-06-12 | PDF 1.4 MB |
| SAR Report 865221_caldata | RF Exposure Info | 2017-06-12 | PDF 1.3 MB |
| SAR Report IntelliVue MP2 | RF Exposure Info | 2017-06-12 | PDF 1.4 MB |
| SAR Report IntelliVue MP2 _caldata | RF Exposure Info | 2017-06-12 | PDF 1.3 MB |
| MPE Estimation | RF Exposure Info | 2017-05-16 | PDF 336.6 KB |
| block diagram Metadata only | Block Diagram | PDF 524 KB | |
| schematics Metadata only | Schematics | PDF 895 KB | |
| Operational Description Metadata only | Operational Description | PDF 724.7 KB | |
| sw_security_description Metadata only | Operational Description | PDF 66.7 KB |
Application Information
| Application ID | ZkWVejlYwQSez1rwc0lLXA== |
|---|---|
| Final Action Date | 2017-06-12 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0017950635 |
| Model | WLANBV3 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | WLAN Module IEEE 802.11 a/b/g/n |
| Responsible Party | Delroy Smith, Principal Scientist / Project Leader, delroy.smith@philips.com , + 1 978 659 3382 |
| Test Firm | Gerald Schmidt, CTC advanced GmbH, mail@ctcadvanced.com  , 49-681-598-0 |
| TCB Email | TCB@ctcadvanced.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is conducted. This device supports 802.11a and 802.11n with a 20 MHz and 40 MHz bandwidth mode. Approval is for operation as a client only device without radar detection or ad-hoc capability. RF exposure compliance is addressed for 1.1310 and 2.1091 MPE limits. Integrators and End Users must be provided with transmitter operation conditions for satisfying RF exposure compliance. Class II permissive change to allow specific portable host configiurations that are collocated with with module FCC ID: PQC-SRRBV1. The highest reported SAR values for body and simultaneous transmission conditions across all devices under this FCC ID are 0.48 W/kg and 0.53 W/kg respectively. |
