EX21L EXCITER (RFID SYSTEM) Test Setup Photos - FCC ID PQG-EX21L

FCC ID PQG-EX21L

TEST SETUP PHOTOS

EXCITER (RFID SYSTEM)

by Lyngsoe Systems Ltd.

Document preview loads when visible.

Document Details

FCC IDPQG-EX21L
Document ID489555
Document TypeTest Setup Photos
DescriptionTEST SETUP PHOTOS
Document TitleLYT-018--TSup
ApplicantLyngsoe Systems Ltd.
Equipment ClassEXCITER (RFID SYSTEM)
Product CodeEX21L
Application IDdgEWaPfKT8FU6QYH3c6aMQ==
Application PurposeClass II Permissive Change
Application Date2004-11-18
Frequency Range0.125 MHz
FRN0004944047
Test FirmUltraTech Engineering Labs Inc.
Certified ByDONALD FERGUSON VP
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-11-18
Available2004-11-18
Created2004-11-11
Modified2004-11-11
Pages3
File TypeAdobe Acrobat PDF
File Size412239
File SHA-25600687bde37cbc24e4a8fef4f7a70c92ec84be8896c2d3452f2bdb15a30705652
PDF Metadata AuthorAnca
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows) Anca
FCC.gov SourcesFCC.gov 489555
