44308TX49 RC Airplane Schematics - FCC ID PQN44308TX49

FCC ID PQN44308TX49

Circuit Diagram

RC Airplane

by Spin Master Toys Far East Ltd.

Document preview loads when visible.

Document Details

FCC IDPQN44308TX49
Document ID853130
Document TypeSchematics
DescriptionCircuit Diagram
Document TitleProtel Schematic
ApplicantSpin Master Toys Far East Ltd.
Equipment ClassRC Airplane
Product Code44308TX49
Application IDY7BiThig7QZsmaQaSiqStQ==
Application PurposeOriginal Equipment
Application Date2007-10-09
Frequency Range49.86 MHz
FRN0018197608
Test FirmIntertek Testing Services Hong Kong
Certified ByAnthony Chan Assistant Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2007-10-09
Available2007-10-09
Created2007-09-22
Modified2007-10-05
Pages1
File TypeAdobe Acrobat PDF
File Size24907
File SHA-256f17d42dc78176df96d855e0a023056602b065538ebf83b0bd7bdad2e0797e22a
PDF Metadata Authorsd50059
PDF Metadata CreatorpdfFactory Pro www.pdffactory.com
PDF Metadata ProducerpdfFactory Pro 1.64 (Windows XP Chinese)
FCC.gov SourcesFCC.gov 853130
