44438M03RX2G4 ARH RDC Helix X4 Stunt... - FCC ID PQN44438M03RX2G4

FCC ID PQN44438M03RX2G4

Block Diagram

ARH RDC Helix X4 Stunt Quad Copter

by Spin Master Toys Far East Ltd.

Document preview loads when visible.

Document Details

FCC IDPQN44438M03RX2G4
Document ID2302711
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Titleuntitled
ApplicantSpin Master Toys Far East Ltd.
Equipment ClassARH RDC Helix X4 Stunt Quad Copter
Product Code44438M03RX2G4
Application ID8Jf9UWpEXqZajbuyCOEH7Q==
Application PurposeOriginal Equipment
Application Date2014-06-23
Frequency Range2412-2460 MHz
FRN0018197608
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByAndy Wong
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2014-06-23
Available2014-06-23
Created2014-04-29
Modified2014-06-17
Pages3
File TypeAdobe Acrobat PDF
File Size798957
File SHA-256ecde7d00cb3eb3dc8e60413fc7ea1d22ae2dd3f7b1f99b8e167a0798a7000431
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 2302711
