FCC ID PQN44578RX2G4
ARH RDC HelixSentinelDrone Receiver
by Spin Master Toys Far East Ltd.
Grantee Code: PQN Product Code: 44578RX2G4
Latest application date: 2016-07-19
Device Images
FCC ID Device Details
| FCC ID | PQN44578RX2G4 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PQN |
| Product Code | 44578RX2G4 |
| Applicant Business | Spin Master Toys Far East Ltd. |
| Related Domains |  spinmaster.com  intertek.com |
| Equipment Class | ARH RDC HelixSentinelDrone Receiver |
| Test Firm | Intertek Testing Services Hong Kong Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2407-2440 MHz | Original Equipment | 2016-07-19 |
| 2412-2462 MHz | Original Equipment | 2016-07-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-19 | PDF 1.4 MB |
| Internal Photos | Internal Photos | 2016-07-19 | PDF 1.4 MB |
| External Photos | External Photos | 2016-07-19 | PDF 81.1 KB |
| Label Artwork and Location | ID Label/Location Info | 2016-07-19 | PDF 4.2 MB |
| Block Diagram | Block Diagram | 2016-07-19 | PDF 436.3 KB |
| Circuit Diagram | Schematics | 2016-07-19 | PDF 756.9 KB |
| Technical Description | Operational Description | 2016-07-19 | PDF 138.4 KB |
| Radiated Emission | Test Setup Photos | 2016-07-19 | PDF 182.7 KB |
| Test Report | Test Report | 2016-07-19 | PDF 259.3 KB |
| Test Report | Test Report | 2016-07-18 | PDF 735.9 KB |
| Letter of Agency | Cover Letter(s) | 2016-07-19 | PDF 27.3 KB |
| Analysis Report | RF Exposure Info | 2016-07-19 | PDF 389.5 KB |
Application Information
| Application ID | DHTEj3XU2yGklK8/9ztsiw== |
|---|---|
| Final Action Date | 2016-07-19 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0018197608 |
| Model | 44578RX2G4 |
| Frequency Range | 2407-2440 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | ARH RDC HelixSentinelDrone Receiver |
| Responsible Party | Tommy So, Senior Quality Manager, tommys@spinmaster.com , 852-2301-3822 |
| Agent | Terry Terry Terry, Intertek Testing Services Hong Kong Ltd. |
| Technical Contact | Terry Chan, Intertek Testing Services Hong Kong Ltd., terry.chan@intertek.com , (852) 2173 8888 |
| Non-Technical Contact | Terry Chan, Intertek Testing Services Hong Kong Ltd., terry.chan@intertek.com , (852) 2173 8888 |
| Test Firm | Billy Chow, Intertek Testing Services Hong Kong Ltd., billy.chow@intertek.com , 85221738528 |
| TCB Email | TCB_Admin@intertek.com |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| DHTEj3XU2yGklK8/9ztsiw== | 2016-07-19 | Original Equipment |
| mSk3GLhMRNBNNp8/1zzIVQ== | 2016-07-18 | Original Equipment |
Grants
TCB Grant - Application mSk3GLhMRNBNNp8/1zzIVQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Intertek Testing Services NA, Inc. 70 Codman Hill Road Boxborough, MA 01719 |
Date of Grant: 07/18/2016 Application Dated: 07/18/2016 |
| Spin Master Toys Far East Ltd. |
| Room 1113, 11/F., Chinachem Golden Plaza, |
| 77 Mody Road, Tsim Sha Tsui East,P.O. Box N/A, |
| Kowloon, Hong Kong |
| Attention: Tommy So , Senior Quality Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PQN44578RX2G4 |
| Name of Grantee: | Spin Master Toys Far East Ltd. |
| Equipment Class: | Digital Transmission System |
| Notes: | ARH RDC HelixSentinelDrone Receiver |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.0743 |
| The output power listed is conducted. This device must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter except as described in this composite filing. End-users must be informed of the operating requirements for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
