RED199X1 Microwave Oven Label Diagram - FCC ID PR4RED199X1

FCC ID PR4RED199X1

Label & Label Location

Microwave Oven

by Whirlpool Microwave Products Development Limited.

Document preview loads when visible.

Document Details

FCC IDPR4RED199X1
Document ID6399295
Document TypeID Label/Location Info
DescriptionLabel & Label Location
Document TitleID Label and Label Location
ApplicantWhirlpool Microwave Products Development Limited.
Equipment ClassMicrowave Oven
Product CodeRED199X1
Application IDAml8ah99Wo5EyVVyBRttnA==
Application PurposeClass II Permissive Change
Application Date2023-03-08
Frequency Range2450 MHz
FRN0012635595
Test FirmShenzhen Accurate Technology Co., Ltd.
Certified ByBobo Lin
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2023-03-08
Available2023-03-08
Created2023-02-17
Modified2023-02-17
Pages1
File TypeAdobe Acrobat PDF
File Size577892
File SHA-256414766cbd2e3ab69820117adcbbf79da0cab0abec22f3726671d47cf2c1efc1b
PDF Metadata AuthorAdministrator
PDF Metadata ProducerMicrosoft: Print To PDF
FCC.gov SourcesFCC.gov 6399295
