TSEQ2401 2.4GHz USB DONGLE Teardown... - FCC ID PTITSEQ-2401

FCC ID PTITSEQ-2401

INTERNAL PHOTOS

2.4GHz USB DONGLE

by TopSeed Technology Corp.

Document preview loads when visible.

Document Details

FCC IDPTITSEQ-2401
Document ID544843
Document TypeInternal Photos
DescriptionINTERNAL PHOTOS
Document TitleTSEQ-2401 Pho
ApplicantTopSeed Technology Corp.
Equipment Class2.4GHz USB DONGLE
Product CodeTSEQ2401
Application IDS2TSTacz4ewmuCOxudd14g==
Application PurposeOriginal Equipment
Application Date2005-05-23
Frequency Range2402-2479 MHz
FRN0006288591
Test FirmTraining Research Co., Ltd
Certified ByCHUNG PING CHI MANAGER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/07/2005
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2005-05-23
Available2005-07-07
Created2005-05-21
Modified2005-05-21
Pages4
File TypeAdobe Acrobat PDF
File Size241777
File SHA-25684dc81aac5a2d3ecca71270fd6e3c4ab97579ee886f11bfa7d803ea4ba669ad7
PDF Metadata AuthorWeng1
PDF Metadata ProducerAcrobat Distiller 5.0.5 (Windows) Weng1
FCC.gov SourcesFCC.gov 544843
