HTMD004B NXP5169LIGHT MODULE Test Setup Photos - FCC ID PUW-HTMD004B

FCC ID PUW-HTMD004B

Setup Photos

NXP5169LIGHT MODULE

by JiangSu HuiTong Group Co.,Ltd

Document preview loads when visible.

Document Details

FCC IDPUW-HTMD004B
Document ID4035368
Document TypeTest Setup Photos
DescriptionSetup Photos
Document TitleEXHIBIT C_TEST SETUP PHOTOGRAPHS
ApplicantJiangSu HuiTong Group Co.,Ltd
Equipment ClassNXP5169LIGHT MODULE
Product CodeHTMD004B
Application IDMYuzIDMlt0QTlG7w1U/c7A==
Application PurposeOriginal Equipment
Application Date2018-10-15
Frequency Range2405-2480 MHz
FRN0022028153
Test FirmBay Area Compliance Laboratories Corp. (Kunshan)
Certified ByYin Yan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2018-10-15
Available2018-10-15
Created2018-10-08
Modified2018-10-15
Pages2
File TypeAdobe Acrobat PDF
File Size1016572
File SHA-256af3fb76292db221d697287fd2eb662a9902a96d13d53fb5e7a9f25b53a900b4d
PDF Metadata Authorbaclks150
PDF Metadata Producerbaclks150 Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 4035368
