460035 Quint Band Bi-Directional Direct... - FCC ID PWO460035

FCC ID PWO460035

External Photos

Quint Band Bi-Directional Direct Contact Coupling Amplifier

by Wilson Electronics, LLC

Document preview loads when visible.

Document Details

FCC IDPWO460035
Document ID3497069
Document TypeExternal Photos
DescriptionExternal Photos
ApplicantWilson Electronics, LLC
Equipment ClassQuint Band Bi-Directional Direct Contact Coupling Amplifier
Product Code460035
Application IDWdDHWWStrsFy51Or9axA9g==
Application PurposeOriginal Equipment
Application Date2017-08-05
Frequency Range1710-1755 MHz
FRN0017528332
Test FirmSMART EC Product Testing Services
Certified ByHoosamuddin Bandukwala President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date02/01/2018
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-08-04
Available2018-02-01
Created2017-07-11
Modified2017-07-11
Pages6
File TypeAdobe Acrobat PDF
File Size3778723
File SHA-2565c8756bd00fedddab333c9c011ffc12b93b120060adfbe67be4ce2fd78ce9984
PDF Metadata ProducerAdobe Acrobat 10.0 Adobe Acrobat 10.0 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 3497069
