M81 GSM 900/1800/1900 Mobile Phone with BT Test... - FCC ID PWX-M81
FCC ID PWX-M81
Test Setup Photos
GSM 900/1800/1900 Mobile Phone with BT
Document preview loads when visible.
Document Details
| FCC ID | PWX-M81 |
|---|---|
| Document ID | 682222 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | 2-4375-01-03_06_Part15-delta |
| Applicant | BenQ Mobile GmbH & Co. OHG |
| Equipment Class | GSM 900/1800/1900 Mobile Phone with BT |
| Product Code | M81 |
| Application ID | 7orMO8H0TTZDFYqA9fIDlg== |
| Application Purpose | Original Equipment |
| Application Date | 2006-07-18 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0014952428 |
| Test Firm | CTC advanced GmbH |
| Certified By | Wolfgang Kösters |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2006-07-18 |
| Available | 2006-07-18 |
| Created | 2006-07-11 |
| Modified | 2006-07-11 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 79724 |
| File SHA-256 | 00ac1e658eb3658fe83ba4e9bfb608a8af1f96923dac449ca3c7aa5948d52884 |
| PDF Metadata Author | RSC-8412 |
| PDF Metadata Producer | PScript5.dll Version 5.2.2 Acrobat Distiller 6.0 (Windows) |
| FCC.gov Sources | FCC.gov 682222, FCC.gov 682203 |
