500 Rugged PDA Test Setup Photos - FCC ID PX9500
FCC ID PX9500
Test Setup Photos_SAR
Rugged PDA
by Winmate Inc.
Document preview loads when visible.
Document Details
| FCC ID | PX9500 |
|---|---|
| Document ID | 3320669 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos_SAR |
| Document Title | TEST SETUP PHOTO |
| Applicant | Winmate Inc. |
| Equipment Class | Rugged PDA |
| Product Code | 500 |
| Application ID | 4e5k5xi5J6Kncax54Idrag== |
| Application Purpose | Original Equipment |
| Application Date | 2017-03-20 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0026153650 |
| Test Firm | Shenzhen BALUN Technology Co.,Ltd. |
| Certified By | Wu Xuewen Certification Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2017-03-17 |
| Available | 2017-03-20 |
| Created | 2017-12-26 |
| Modified | 2017-12-26 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 429231 |
| File SHA-256 | 587bc50db01faec848cec104f1f40c9d6ff0dc5ca21ca552cf5e5b471998a50a |
| PDF Metadata Author | 文琳 |
| PDF Metadata Producer | GPL Ghostscript 9.18 文琳 |
| FCC.gov Sources | FCC.gov 3320669, FCC.gov 3320653 |
