HL2505 Academia Teardown Internal Photos - FCC ID PXK-HL2505

FCC ID PXK-HL2505

Internal Photos

Academia

by ECORE TECHNOLOGY COMPANY LIMITED

Document preview loads when visible.

Document Details

FCC IDPXK-HL2505
Document ID2327498
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleExternal Photo
ApplicantECORE TECHNOLOGY COMPANY LIMITED
Equipment ClassAcademia
Product CodeHL2505
Application IDTaSYbJnfRmzfgfsBC2KEyA==
Application PurposeOriginal Equipment
Application Date2014-07-17
Frequency Range2402-2480 MHz
FRN0022032825
Test FirmDongguan NTC Co.,Ltd.,
Certified ByLiucheng Liu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-07-17
Available2014-07-17
Created2014-07-07
Modified2014-07-07
Pages5
File TypeAdobe Acrobat PDF
File Size778311
File SHA-256d7d4e7910714f05b7ccad6388b523f3c40e0d693e1e21bee032eb22aaea372fb
PDF Metadata AuthorAdministrator
PDF Metadata ProducerAcrobat Distiller 7.0.5 (Windows) Administrator
FCC.gov SourcesFCC.gov 2327498, FCC.gov 2327478
