FCC ID PY316100334
AC1200 WiFi Range Extender
by Netgear Incorporated
Grantee Code: PY3 Product Code: 16100334
Latest application date: 2017-10-17
Device Images
FCC ID Device Details
| FCC ID | PY316100334 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | PY3 |
| Product Code | 16100334 |
| Applicant Business | Netgear Incorporated 🇺🇸 |
| Related Domains |  netgear.com |
| Equipment Class | AC1200 WiFi Range Extender |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2017-10-17 |
| 2412-2462 MHz | Original Equipment | 2016-08-05 |
| 5180-5240 MHz | Original Equipment | 2016-08-05 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-08-05 | PDF 1.9 MB |
| Users Manual (Statement) | Users Manual | 2016-08-05 | PDF 7.5 KB |
| Internal Photos | Internal Photos | 2016-08-05 | PDF 3.7 MB |
| External Photos | External Photos | 2016-08-05 | PDF 901.3 KB |
| Label Location | ID Label/Location Info | 2016-08-05 | PDF 92.5 KB |
| Label Sample | ID Label/Location Info | 2016-08-05 | PDF 481.8 KB |
| Test Set Up Photos rev.pdf | Test Setup Photos | 2017-10-17 | PDF 357.1 KB |
| Test Set Up Photo | Test Setup Photos | 2016-08-05 | PDF 290.8 KB |
| Test Report (DFS) rev.pdf | Test Report | 2017-10-17 | PDF 3.3 MB |
| Test Report (NII) rev.pdf | Test Report | 2017-10-17 | PDF 540.3 KB |
| Test Report (DTS)_rev | Test Report | 2016-08-05 | PDF 2.3 MB |
| Test Report (NII)_rev | Test Report | 2016-08-05 | PDF 783.1 KB |
| Attestation (DFS Declaration).pdf | Attestation Statements | 2017-10-17 | PDF 256 KB |
| Attestation (Channel and Mode Declaration) | Attestation Statements | 2016-08-05 | PDF 203.5 KB |
| Confidentiality Request (Long term) rev.pdf | Cover Letter(s) | 2017-10-17 | PDF 121.5 KB |
| Cover Letter (Agent Authorization).pdf | Cover Letter(s) | 2017-10-17 | PDF 250 KB |
| Description of Change rev1.pdf | Cover Letter(s) | 2017-10-17 | PDF 22.7 KB |
| Confidentiality Request (long-term) | Cover Letter(s) | 2016-08-05 | PDF 70.4 KB |
| Cover Letter (Agent Authorization) | Cover Letter(s) | 2016-08-05 | PDF 86.2 KB |
| RF Exposure Info (MPE).pdf | RF Exposure Info | 2017-10-17 | PDF 65.3 KB |
| RF Exposure Info (MPE)_rev | RF Exposure Info | 2016-08-05 | PDF 64.8 KB |
| Block Diagram Metadata only | Block Diagram | PDF 127.8 KB | |
| Schematics Metadata only | Schematics | PDF 518.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 18.1 KB | |
| Operational Description rev.pdf Metadata only | Operational Description | PDF 21 KB | |
| Software Operating Description Metadata only | Operational Description | PDF 239.8 KB | |
| Software Operational Description.pdf Metadata only | Operational Description | PDF 339.8 KB |
Application Information
| Application ID | lynIQPgjaDDwZ3evCLxczg== |
|---|---|
| Final Action Date | 2017-10-17 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0022158786 |
| Model | 16100334 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | AC1200 WiFi Range Extender |
| Responsible Party | David Kay, david.kay@netgear.com , 4088903160 |
| Agent | Andrea Andrea Andrea, Bureau Veritas Consumer Products Services (H.K.) L, andrea.hsia@tw.bureauveritas.com  , 88633183232 |
| Test Firm | Richard Chen, Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch, richard.chen@bureauveritas.com  , +886-(0)3-260-0884 |
| TCB Email | tcb@us.bureauveritas.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change for adding DFS bands through software enabling. Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| lynIQPgjaDDwZ3evCLxczg== | 2017-10-17 | Class II permissive change or modification of presently authorized equipment |
| AItRZ+EX/AelYhhGZ7DK5Q== | 2016-08-05 | Original Equipment |
| 0+oIA3Xe3glchO6git6ceg== | 2016-08-05 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application lynIQPgjaDDwZ3evCLxczg==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 10/17/2017 Application Dated: 09/20/2017 |
| Netgear Incorporated |
| 350 East Plumeria Drive |
| San Jose, CA 95134 |
| Attention: David Kay |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY316100334 |
| Name of Grantee: | Netgear Incorporated |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1200 WiFi Range Extender |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.233 | ||
| 38 CC MO ND | 15E | 5500.0 - 5700.0 | 0.232 | ||
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.468 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.508 |
| Class II Permissive Change for adding DFS bands through software enabling. Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application lynIQPgjaDDwZ3evCLxczg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Netgear Incorporated 350 East Plumeria Drive San Jose, CA 95134 United States |
Date of Grant: 10/17/2017 Application Dated: 09/20/2017 |
| Attention: David Kay |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY316100334 |
| Name of Grantee: | Netgear Incorporated |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1200 WiFi Range Extender |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.233 | ||
| 38 CC MO ND | 15E | 5500.0 - 5700.0 | 0.232 | ||
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.468 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.508 |
| Class II Permissive Change for adding DFS bands through software enabling. Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 08/05/2016 Application Dated: 08/05/2016 |
| Netgear Incorporated |
| 350 East Plumeria Drive |
| San Jose, CA 95134 |
| Attention: David Kay |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY316100334 |
| Name of Grantee: | Netgear Incorporated |
| Equipment Class: | Digital Transmission System |
| Notes: | AC1200 WiFi Range Extender |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.472 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application AItRZ+EX/AelYhhGZ7DK5Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Netgear Incorporated 350 East Plumeria Drive San Jose, CA 95134 United States |
Date of Grant: 08/05/2016 Application Dated: 08/05/2016 |
| Attention: David Kay |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY316100334 |
| Name of Grantee: | Netgear Incorporated |
| Equipment Class: | Digital Transmission System |
| Notes: | AC1200 WiFi Range Extender |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.472 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. One Distribution Center Circle Suite #1 Littleton, MA 01460 |
Date of Grant: 08/05/2016 Application Dated: 08/05/2016 |
| Netgear Incorporated |
| 350 East Plumeria Drive |
| San Jose, CA 95134 |
| Attention: David Kay |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY316100334 |
| Name of Grantee: | Netgear Incorporated |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1200 WiFi Range Extender |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.468 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.508 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 0+oIA3Xe3glchO6git6ceg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Netgear Incorporated 350 East Plumeria Drive San Jose, CA 95134 United States |
Date of Grant: 08/05/2016 Application Dated: 08/05/2016 |
| Attention: David Kay |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY316100334 |
| Name of Grantee: | Netgear Incorporated |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | AC1200 WiFi Range Extender |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.468 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.508 |
| Power listed is the maximum combined conducted output power. End-users and responsible parties must be provided with operating and installation instructions to ensure RF exposure compliance. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter, except the collocation as described in this filing or in accordance with FCC multi-transmitter product guidelines. Operations in the 5.15-5.25GHz band are restricted to indoor usage only. This device has 20 MHz, 40 MHz and 80 MHz bandwidth mode. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
