16200341 Orbi Router, Orbi Pro Router, Orbi... - FCC ID PY316200341
FCC ID PY316200341
Internal Photos_RBR50, RBS50 rev.pdf
Orbi Router, Orbi Pro Router, Orbi Satellite, Orbi Pro Satellite
Document preview loads when visible.
Document Details
| FCC ID | PY316200341 |
|---|---|
| Document ID | 3926847 |
| Document Type | Internal Photos |
| Description | Internal Photos_RBR50, RBS50 rev.pdf |
| Document Title | 160621C27V _EUT Photo__RBR50, RBS50 |
| Applicant | Netgear Incorporated |
| Equipment Class | Orbi Router, Orbi Pro Router, Orbi Satellite, Orbi Pro Satellite |
| Product Code | 16200341 |
| Application ID | 0NQfEf9mrAezQvt9F7QhYw== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2018-07-17 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0022158786 |
| Test Firm | Bureau Veritas CPS (H.K.) Ltd., Taoyuan Branch |
| Certified By | Amanda Wu Senior Specialist |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 01/13/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2018-07-17 |
| Available | 2019-01-13 |
| Created | 2018-07-13 |
| Modified | 2018-07-13 |
| Pages | 11 |
| File Type | Adobe Acrobat PDF |
| File Size | 2298374 |
| File SHA-256 | 684ad9cc971e88faed80e550f3d8bcda1a8e7eef31dfabd8982ccf87db38f3a1 |
| PDF Metadata Author | pochien |
| PDF Metadata Producer | Acrobat Distiller 11.0 (Windows) pochien |
| FCC.gov Sources | FCC.gov 3926847, FCC.gov 3926901 |
