18300419 Orbi Satellite Teardown Internal... - FCC ID PY318300419

FCC ID PY318300419

Internal Photos

Orbi Satellite

by Netgear Incorporated

Document preview loads when visible.

Document Details

FCC IDPY318300419
Document ID4110870
Document TypeInternal Photos
DescriptionInternal Photos
Document Title181026C02 (EUT photo)_FCC
ApplicantNetgear Incorporated
Equipment ClassOrbi Satellite
Product Code18300419
Application IDd6z2M1Bo+/7jM+a4zOsynw==
Application PurposeOriginal Equipment
Application Date2018-12-20
Frequency Range2412-2462 MHz
FRN0022158786
Test FirmBureau Veritas CPS(H.K.) Ltd., Taoyuan Branch
Certified ByAmanda Wu
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/19/2019
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2018-12-20
Available2019-06-19
Created2018-11-07
Modified2018-11-07
Pages11
File TypeAdobe Acrobat PDF
File Size1785831
File SHA-2560abd08b5d26c03f6c85dd80802c362229c291ddcd4e7b1b698eb157fe0c45b8b
PDF Metadata Authorpettchen
PDF Metadata Producerpettchen Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 4110870, FCC.gov 4110886
