FCC ID PY7-PM0817
GSM/WCDMA/LTE Phone + Bluetooth, DTS/UNII a/b/g/n/ac, ANT+, NFC&GPS;
by Sony Corporation
Grantee Code: PY7 Product Code: PM0817
Latest application date: 2016-02-12
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 824.2-848.8 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-12 |
| 824.2-848.8 MHz | Original Equipment | 2015-04-21 |
| 5180-5240 MHz | Original Equipment | 2015-04-21 |
| 2402-2480 MHz | Original Equipment | 2015-04-21 |
| 13.56 MHz | Original Equipment | 2015-04-21 |
| 2402-2480 MHz | Original Equipment | 2015-04-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| SAR FCC DoC Leaflet | Users Manual | 2015-04-21 | PDF 830.7 KB |
| User Guide | Users Manual | 2015-04-21 | PDF 2.9 MB |
| Internal Photos | Internal Photos | 2015-04-21 | PDF 367.1 KB |
| External Photos | External Photos | 2015-04-21 | PDF 175.5 KB |
| Label Location | ID Label/Location Info | 2015-04-21 | PDF 241.1 KB |
| SAR test photos | Test Setup Photos | 2016-02-12 | PDF 629.5 KB |
| Test Setup Photos | Test Setup Photos | 2015-04-21 | PDF 807.8 KB |
| Test Setup Photos SAR | Test Setup Photos | 2015-04-21 | PDF 1.1 MB |
| DFS Report | Test Report | 2015-04-21 | PDF 579.5 KB |
| Test Report | Test Report | 2015-04-21 | PDF 3 MB |
| Test Report ANT+ | Test Report | 2015-04-21 | PDF 751.7 KB |
| Test Report BLE | Test Report | 2015-04-21 | PDF 1.2 MB |
| Test Report GPS | Test Report | 2015-04-21 | PDF 333.9 KB |
| Test Report GSM | Test Report | 2015-04-21 | PDF 1.9 MB |
| Test Report LTE | Test Report | 2015-04-21 | PDF 993.2 KB |
| Test Report NFC | Test Report | 2015-04-21 | PDF 1.1 MB |
| Test Report USB | Test Report | 2015-04-21 | PDF 390.1 KB |
| Test Report WCDMA | Test Report | 2015-04-21 | PDF 1.6 MB |
| Test Report WLAN 2.4 GHz part 1 | Test Report | 2015-04-21 | PDF 5.2 MB |
| Test Report WLAN 2.4 GHz part 2 | Test Report | 2015-04-21 | PDF 3.6 MB |
| Test Report WLAN 5 GHz part 1 | Test Report | 2015-04-21 | PDF 4.5 MB |
| Test Report WLAN 5 GHz part 2 | Test Report | 2015-04-21 | PDF 3.1 MB |
| Test Report WLAN 5 GHz part 3 | Test Report | 2015-04-21 | PDF 2.7 MB |
| Test Report WLAN 5.8 GHz | Test Report | 2015-04-21 | PDF 4.6 MB |
| Agent Auth | Cover Letter(s) | 2016-02-12 | PDF 211.6 KB |
| CIIPC Cover Letter | Cover Letter(s) | 2016-02-12 | PDF 13.7 KB |
| Confidentiality | Cover Letter(s) | 2016-02-12 | PDF 47.8 KB |
| Agent Authorization | Cover Letter(s) | 2015-04-21 | PDF 211.6 KB |
| Request for Confidentiality | Cover Letter(s) | 2015-04-21 | PDF 90.6 KB |
| Test Data Re-Use Justification | Cover Letter(s) | 2015-04-21 | PDF 90.6 KB |
| SAR Report | RF Exposure Info | 2016-02-12 | PDF 3.6 MB |
| SAR Report Appendix A | RF Exposure Info | 2016-02-12 | PDF 171.8 KB |
| SAR Report Appendix B1 | RF Exposure Info | 2016-02-12 | PDF 3.6 MB |
| SAR Report Appendix B2 | RF Exposure Info | 2016-02-12 | PDF 4.7 MB |
| SAR Report Appendix C1 | RF Exposure Info | 2016-02-12 | PDF 3.8 MB |
| SAR Report Appendix C2 | RF Exposure Info | 2016-02-12 | PDF 3.9 MB |
| SAR Report Appendix D1 | RF Exposure Info | 2016-02-12 | PDF 4.6 MB |
| SAR Report Appendix D2 | RF Exposure Info | 2016-02-12 | PDF 4.7 MB |
| SAR Report Appendix D3 | RF Exposure Info | 2016-02-12 | PDF 4.7 MB |
| SAR Report Appendix D4 | RF Exposure Info | 2016-02-12 | PDF 4.6 MB |
| SAR Report Appendix E1 | RF Exposure Info | 2016-02-12 | PDF 5.3 MB |
| SAR Report Appendix E2 | RF Exposure Info | 2016-02-12 | PDF 5.4 MB |
| SAR Report Appendix E3 | RF Exposure Info | 2016-02-12 | PDF 4.7 MB |
| SAR Report Appendix E4 | RF Exposure Info | 2016-02-12 | PDF 5.1 MB |
| SAR Report Appendix E5 | RF Exposure Info | 2016-02-12 | PDF 4.9 MB |
| SAR Report part 1 | RF Exposure Info | 2015-04-21 | PDF 1.3 MB |
| SAR Report part 2 | RF Exposure Info | 2015-04-21 | PDF 4.6 MB |
| SAR Report part 3 | RF Exposure Info | 2015-04-21 | PDF 3 MB |
| SAR Report part 4 | RF Exposure Info | 2015-04-21 | PDF 4.2 MB |
| Block Diagram Metadata only | Block Diagram | PDF 1.5 MB | |
| Schematics Metadata only | Schematics | PDF 1.8 MB | |
| Antenna Description Metadata only | Operational Description | PDF 127.2 KB | |
| Antenna Tuner Metadata only | Operational Description | PDF 154.9 KB | |
| KDB392632 Metadata only | Operational Description | PDF 166.3 KB | |
| Operational Description Metadata only | Operational Description | PDF 1.5 MB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 1.1 MB | |
| Tune-Up Procedure Metadata only | Parts List/Tune Up Info | PDF 1.1 MB |
Application Information
| Application ID | VaT6bsLEAoxP70OdgbqFaA== |
|---|---|
| Final Action Date | 2016-02-12 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0018919456 |
| Model | PM0817 |
| Frequency Range | 824.2-848.8 MHz |
| Equipment Class | PCE - PCS Licensed Transmitter held to ear |
| Device Description | GSM/WCDMA/LTE Phone + Bluetooth, DTS/UNII a/b/g/n/ac, ANT+, NFC&GPS; |
| Responsible Party | Mika Kaneko, Chief Regulatory Compliance Manager, Mika.Kaneko@sony.com  , +81367103225 |
| Test Firm | Gang Ma, Sony Mobile Type Approval China Laboratory, Gang.Ma@sonymobile.com  , 0086(0)10-80481188 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | Yes |
| Grant Comments | Class II Permissive Change. Power output is ERP for Part 22 and EIRP for Part 24 and Part 27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.67 W/kg; Body-worn 1.05 W/kg; Product Specific (Wireless Router): 1.05 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell, 1900 MHz PCS and 2500 MHz BRS operations. This device contains ANT+, Bluetooth, BLE, NFC and WLAN transmitters. This device has 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 7 and 41. Support for Rel.10 LTE is limited to network enhancement features. Carrier aggregation is not implemented. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| VaT6bsLEAoxP70OdgbqFaA== | 2016-02-12 | Class II permissive change or modification of presently authorized equipment |
| tWRZUI1SQv17DtJlQ1MBJg== | 2015-04-21 | Original Equipment |
| rI0wGsTDSemAWeBmSvFQoA== | 2015-04-21 | Original Equipment |
| YBFnVGHBBA49HjjIPsQreQ== | 2015-04-21 | Original Equipment |
| BuWMgi8TEVTK+Pp946lcYA== | 2015-04-21 | Original Equipment |
| 7o4EKMKgznS3xbZEaXo26g== | 2015-04-21 | Original Equipment |
| 7klJ32xA3fL8GMSCWCUY/g== | 2015-04-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | CC | ||||
| 13.56 MHz | 15C | CC | |||
| 824.2-848.8 MHz | 0.3837 | 0.1ppm | 246KG7W | 22H | BC |
| 826.4-846.6 MHz | 0.3141 | 0.1ppm | 4M13F9W | 22H | BC |
| 1850.2-1909.8 MHz | 1.074 | 0.1ppm | 245KGXW | 24E | BC |
| 1850.2-1909.8 MHz | 0.5861 | 0.1ppm | 246KG7W | 24E | BC |
| 1852.4-1907.6 MHz | 0.2965 | 0.1ppm | 4M13F9W | 24E | BC |
| 2402-2480 MHz | 15C | CC | |||
| 2402-2480 MHz | 0.0115000 | 15C | CC | ||
| 2402-2480 MHz | 0.0014 | 15C | CC | ||
| 2412-2462 MHz | 0.2443 | 15C | CC | ||
| 2501-2685 MHz | 0.2786 | 0.1ppm | 8M99G7D | 27 | BC |
| 2505-2565 MHz | 0.1875 | 0.1ppm | 8M99G7D | 27 | BC |
| 2505-2565 MHz | 0.1524 | 0.1ppm | 8M99W7D | 27 | BC |
| 2506-2680 MHz | 0.2723 | 0.1ppm | 17M9G7D | 27 | BC |
| 2506-2680 MHz | 0.2636 | 0.1ppm | 17M9W7D | 27 | BC |
| 2510-2560 MHz | 0.1387 | 0.1ppm | 17M9W7D | 27 | BC |
| 2510-2560 MHz | 0.1766 | 0.1ppm | 17M9G7D | 27 | BC |
| 5180-5240 MHz | 0.0115 | 15E | 38, CC | ||
| 5260-5320 MHz | 0.029 | 15E | 38, CC | ||
| 5500-5700 MHz | 0.0288 | 15E | 38, CC | ||
| 5745-5825 MHz | 0.3055 | 15E | 38, CC |
Grants
TCB Grant - Application YBFnVGHBBA49HjjIPsQreQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.0115 | ||
| 38 CC | 15E | 5260.0 - 5320.0 | 0.029 | ||
| 38 CC | 15E | 5500.0 - 5700.0 | 0.0288 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.3055 |
| Power output is conducted. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.70 W/kg; Body-worn 0.14 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. This device contains ANT+, Bluetooth, BLE, NFC and GSM/WCDMA/LTE transmitters. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application YBFnVGHBBA49HjjIPsQreQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC | 15E | 5180.0 - 5240.0 | 0.0115 | ||
| 38 CC | 15E | 5260.0 - 5320.0 | 0.029 | ||
| 38 CC | 15E | 5500.0 - 5700.0 | 0.0288 | ||
| 38 CC | 15E | 5745.0 - 5825.0 | 0.3055 |
| Power output is conducted. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.70 W/kg; Body-worn 0.14 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device has a 20 MHz, 40 MHz and 80 MHz bandwidth mode. This device contains ANT+, Bluetooth, BLE, NFC and GSM/WCDMA/LTE transmitters. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 02/12/2016 Application Dated: 02/12/2016 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | PCS Licensed Transmitter held to ear |
| Notes: | GSM/WCDMA/LTE Phone + Bluetooth, DTS/UNII a/b/g/n/ac, ANT+, NFC&GPS |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BC | 22H | 824.2 - 848.8 | 1.0257 | 0.1 PM | 245KGXW |
| BC | 22H | 824.2 - 848.8 | 0.3837 | 0.1 PM | 246KG7W |
| BC | 22H | 826.4 - 846.6 | 0.3141 | 0.1 PM | 4M13F9W |
| BC | 24E | 1850.2 - 1909.8 | 1.074 | 0.1 PM | 245KGXW |
| BC | 24E | 1850.2 - 1909.8 | 0.5861 | 0.1 PM | 246KG7W |
| BC | 24E | 1852.4 - 1907.6 | 0.2965 | 0.1 PM | 4M13F9W |
| BC | 27 | 2505.0 - 2565.0 | 0.1875 | 0.1 PM | 8M99G7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1766 | 0.1 PM | 17M9G7D |
| BC | 27 | 2505.0 - 2565.0 | 0.1524 | 0.1 PM | 8M99W7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1387 | 0.1 PM | 17M9W7D |
| BC | 27 | 2501.0 - 2685.0 | 0.2786 | 0.1 PM | 8M99G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2723 | 0.1 PM | 17M9G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2636 | 0.1 PM | 17M9W7D |
| Class II Permissive Change. Power output is ERP for Part 22 and EIRP for Part 24 and Part 27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.67 W/kg; Body-worn 1.05 W/kg; Product Specific (Wireless Router): 1.05 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell, 1900 MHz PCS and 2500 MHz BRS operations. This device contains ANT+, Bluetooth, BLE, NFC and WLAN transmitters. This device has 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 7 and 41. Support for Rel.10 LTE is limited to network enhancement features. Carrier aggregation is not implemented. |
| BC: | The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. |
EAS Grant - Application VaT6bsLEAoxP70OdgbqFaA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 02/12/2016 Application Dated: 02/12/2016 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | PCS Licensed Transmitter held to ear |
| Notes: | GSM/WCDMA/LTE Phone + Bluetooth, DTS/UNII a/b/g/n/ac, ANT+, NFC&GPS |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BC | 22H | 824.2 - 848.8 | 1.0257 | 0.1 PM | 245KGXW |
| BC | 22H | 824.2 - 848.8 | 0.3837 | 0.1 PM | 246KG7W |
| BC | 22H | 826.4 - 846.6 | 0.3141 | 0.1 PM | 4M13F9W |
| BC | 24E | 1850.2 - 1909.8 | 1.074 | 0.1 PM | 245KGXW |
| BC | 24E | 1850.2 - 1909.8 | 0.5861 | 0.1 PM | 246KG7W |
| BC | 24E | 1852.4 - 1907.6 | 0.2965 | 0.1 PM | 4M13F9W |
| BC | 27 | 2505.0 - 2565.0 | 0.1875 | 0.1 PM | 8M99G7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1766 | 0.1 PM | 17M9G7D |
| BC | 27 | 2505.0 - 2565.0 | 0.1524 | 0.1 PM | 8M99W7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1387 | 0.1 PM | 17M9W7D |
| BC | 27 | 2501.0 - 2685.0 | 0.2786 | 0.1 PM | 8M99G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2723 | 0.1 PM | 17M9G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2636 | 0.1 PM | 17M9W7D |
| Class II Permissive Change. Power output is ERP for Part 22 and EIRP for Part 24 and Part 27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.67 W/kg; Body-worn 1.05 W/kg; Product Specific (Wireless Router): 1.05 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell, 1900 MHz PCS and 2500 MHz BRS operations. This device contains ANT+, Bluetooth, BLE, NFC and WLAN transmitters. This device has 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 7 and 41. Support for Rel.10 LTE is limited to network enhancement features. Carrier aggregation is not implemented. |
| BC: | The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | PCS Licensed Transmitter held to ear |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BC | 22H | 824.2 - 848.8 | 1.0257 | 0.1 PM | 245KGXW |
| BC | 22H | 824.2 - 848.8 | 0.3837 | 0.1 PM | 246KG7W |
| BC | 22H | 826.4 - 846.6 | 0.3141 | 0.1 PM | 4M13F9W |
| BC | 24E | 1850.2 - 1909.8 | 1.074 | 0.1 PM | 245KGXW |
| BC | 24E | 1850.2 - 1909.8 | 0.5861 | 0.1 PM | 246KG7W |
| BC | 24E | 1852.4 - 1907.6 | 0.2965 | 0.1 PM | 4M13F9W |
| BC | 27 | 2505.0 - 2565.0 | 0.1875 | 0.1 PM | 8M99G7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1766 | 0.1 PM | 17M9G7D |
| BC | 27 | 2505.0 - 2565.0 | 0.1524 | 0.1 PM | 8M99W7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1387 | 0.1 PM | 17M9W7D |
| BC | 27 | 2501.0 - 2685.0 | 0.2786 | 0.1 PM | 8M99G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2723 | 0.1 PM | 17M9G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2636 | 0.1 PM | 17M9W7D |
| Power output is ERP for Part 22 and EIRP for Part 24 and Part 27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.67 W/kg; Body-worn 0.84 W/kg; Product Specific (Wireless Router): 0.84 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell, 1900 MHz PCS and 2500 MHz BRS operations. This device contains ANT+, Bluetooth, BLE, NFC and WLAN transmitters. This device has 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 7 and 41. Support for Rel.10 LTE is limited to network enhancement features. Carrier aggregation is not implemented. |
| BC: | The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. |
EAS Grant - Application tWRZUI1SQv17DtJlQ1MBJg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | PCS Licensed Transmitter held to ear |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| BC | 22H | 824.2 - 848.8 | 1.0257 | 0.1 PM | 245KGXW |
| BC | 22H | 824.2 - 848.8 | 0.3837 | 0.1 PM | 246KG7W |
| BC | 22H | 826.4 - 846.6 | 0.3141 | 0.1 PM | 4M13F9W |
| BC | 24E | 1850.2 - 1909.8 | 1.074 | 0.1 PM | 245KGXW |
| BC | 24E | 1850.2 - 1909.8 | 0.5861 | 0.1 PM | 246KG7W |
| BC | 24E | 1852.4 - 1907.6 | 0.2965 | 0.1 PM | 4M13F9W |
| BC | 27 | 2505.0 - 2565.0 | 0.1875 | 0.1 PM | 8M99G7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1766 | 0.1 PM | 17M9G7D |
| BC | 27 | 2505.0 - 2565.0 | 0.1524 | 0.1 PM | 8M99W7D |
| BC | 27 | 2510.0 - 2560.0 | 0.1387 | 0.1 PM | 17M9W7D |
| BC | 27 | 2501.0 - 2685.0 | 0.2786 | 0.1 PM | 8M99G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2723 | 0.1 PM | 17M9G7D |
| BC | 27 | 2506.0 - 2680.0 | 0.2636 | 0.1 PM | 17M9W7D |
| Power output is ERP for Part 22 and EIRP for Part 24 and Part 27. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.67 W/kg; Body-worn 0.84 W/kg; Product Specific (Wireless Router): 0.84 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains GSM/WCDMA/LTE functions that are not operational in U.S. Territories. This filing is only applicable for 850 MHz Cell, 1900 MHz PCS and 2500 MHz BRS operations. This device contains ANT+, Bluetooth, BLE, NFC and WLAN transmitters. This device has 5 MHz, 10 MHz, 15 MHz and 20 MHz bandwidth modes for LTE Bands 7 and 41. Support for Rel.10 LTE is limited to network enhancement features. Carrier aggregation is not implemented. |
| BC: | The output power is continuously variable from the value listed in this entry to 5%-10% of the value listed. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15B | - |
| This device contains ANT+, Bluetooth, BLE, NFC, WLAN and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application rI0wGsTDSemAWeBmSvFQoA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15B | - |
| This device contains ANT+, Bluetooth, BLE, NFC, WLAN and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0115 |
| Power output listed is conducted. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device contains ANT+, BLE, NFC, WLAN and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application BuWMgi8TEVTK+Pp946lcYA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0115 |
| Power output listed is conducted. End-users must be provided with transmitter operating conditions for satisfying RF exposure compliance. This device contains ANT+, BLE, NFC, WLAN and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | |||
| CC | 15C | 13.56 - 13.56 |
| This device contains Bluetooth, BLE, WLAN and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application 7o4EKMKgznS3xbZEaXo26g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | |||
| CC | 15C | 13.56 - 13.56 |
| This device contains Bluetooth, BLE, WLAN and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Sony Corporation |
| 1-7-1 Konan, Minato-ku |
| Tokyo, 108-0075 Japan |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.2443 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0014 |
| Power output is conducted. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.86 W/kg; Body-worn 0.25 W/kg; Product Specific (Wireless Router): 0.25 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains ANT+, Bluetooth, NFC and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application 7klJ32xA3fL8GMSCWCUY/g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Sony Corporation 1-7-1 Konan, Minato-ku Tokyo, 108-0075 Japan |
Date of Grant: 04/21/2015 Application Dated: 04/21/2015 |
| Attention: Mika Kaneko , Chief Regulatory Compliance Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | PY7-PM0817 |
| Name of Grantee: | Sony Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | GSM/WCDMA/LTE mobile phone |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.2443 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.0014 |
| Power output is conducted. Body-worn operations are restricted to belt-clips, holsters or similar accessories that have no metallic component in the assembly and which provide at least 1.5 cm separation between the device and the users body. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR values are: Head: 0.86 W/kg; Body-worn 0.25 W/kg; Product Specific (Wireless Router): 0.25 W/kg; Simultaneous Transmission SAR: 1.52 W/kg. This device contains ANT+, Bluetooth, NFC and GSM/WCDMA/LTE transmitters. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: |
