A1022015 GSM 900/1800/1900 phoen... - FCC ID PY7A1022015

FCC ID PY7A1022015

07 test setup

GSM 900/1800/1900 phoen withBluetooth and GPRS

by Sony Corporation

Document preview loads when visible.

Document Details

FCC IDPY7A1022015
Document ID672240
Document TypeTest Setup Photos
Description07 test setup
Document Title2-4239-12-03_06
ApplicantSony Corporation
Equipment ClassGSM 900/1800/1900 phoen withBluetooth and GPRS
Product CodeA1022015
Application IDkTANEdy7xUGtWUHBr3kikA==
Application PurposeOriginal Equipment
Application Date2006-06-22
Frequency Range2402-2480 MHz
FRN0018919456
Test FirmCTC advanced GmbH
Certified ByPeter Lindeborg Technical Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2006-06-22
Available2006-06-22
Created2006-06-22
Modified2006-06-22
Pages8
File TypeAdobe Acrobat PDF
File Size1637446
File SHA-256dcd993ea5872f34aa16ea761fb757d3ec0eb41e7bfd9e4f1fcedf5140e02eae2
PDF Metadata AuthorRSC-8412
PDF Metadata ProducerRSC-8412 Acrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 672240
