HS58W Bluetooth Headset Test Setup Photos - FCC ID PYAHS-58W

FCC ID PYAHS-58W

Set up photos

Bluetooth Headset

by Microsoft Corporation

Document preview loads when visible.

Document Details

FCC IDPYAHS-58W
Document ID621043
Document TypeTest Setup Photos
DescriptionSet up photos
Document Titleuntitled
ApplicantMicrosoft Corporation
Equipment ClassBluetooth Headset
Product CodeHS58W
Application ID0qSq0oLq5VxraKP4ruDjrg==
Application PurposeOriginal Equipment
Application Date2006-01-19
Frequency Range2402-2480 MHz
FRN0016179699
Test FirmJapan Qlty. Assur. Org. Safety & EMC Ctr
Certified ByRachid Sehb Project Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-01-19
Available2006-01-19
Created2006-01-13
Modified2006-01-13
Pages8
File TypeAdobe Acrobat PDF
File Size209942
File SHA-25612452a1ca72f5bbb42628b2cdf3ce478af6b06e6572b27f034b4eeb6b2cb0d0e
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows)
FCC.gov SourcesFCC.gov 621043
