RM1090 GSM cellular device w/BT, BTLE, WLAN... - FCC ID PYARM-1090

FCC ID PYARM-1090

Test Report BLE

GSM cellular device w/BT, BTLE, WLAN

by Microsoft Corporation

Document preview loads when visible.

Document Details

FCC IDPYARM-1090
Document ID2416538
Document TypeTest Report
DescriptionTest Report BLE
Document TitleTCC Beijing
ApplicantMicrosoft Corporation
Equipment ClassGSM cellular device w/BT, BTLE, WLAN
Product CodeRM1090
Application ID0mE2Zz3DhMA8g5Zwj4cHwQ==
Application PurposeOriginal Equipment
Application Date2014-10-13
Frequency Range2402-2480 MHz
FRN0016179699
Test FirmTCC Microsoft Beijing
Certified ByXu Helen Product Certification Officer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/13/2014
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2014-10-13
Available2014-10-13
Created2014-10-08
Modified2014-10-08
Pages28
File TypeAdobe Acrobat PDF
File Size1126222
File SHA-256f86f5d9873ad7ca3f2ab1d700fc68e0c1a61ce133c3aad13e2895c8ab0dcb2c9
PDF Metadata Authoremcteam conducted 2
PDF Metadata Produceremcteam conducted 2 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 2416538
