FCC ID Q4O-1-21
Cellular Gateway
by Arrayent Health LLC d/b/a Ambio Health
Grantee Code: Q4O Product Code: 121
Latest application date: 2016-12-27
Device Images
FCC ID Device Details
| FCC ID | Q4O-1-21 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | Q4O |
| Product Code | 121 |
| Applicant Business | Arrayent Health LLC d/b/a Ambio Health 🇺🇸 |
| Related Domains |  ambiohealth.com  sgs.com |
| Equipment Class | Cellular Gateway |
| Test Firm | SGS North America, Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 908.4-919.65 MHz | Original Equipment | 2016-12-27 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| user manual | Users Manual | 2016-12-27 | PDF 2.9 MB |
| Internal photos | Internal Photos | 2016-12-27 | PDF 976.1 KB |
| External photos | External Photos | 2016-12-27 | PDF 806.6 KB |
| Label Location | ID Label/Location Info | 2016-12-27 | PDF 228.2 KB |
| Set up photos | Test Setup Photos | 2016-12-27 | PDF 754.1 KB |
| Test Report | Test Report | 2016-12-27 | PDF 1.7 MB |
| Agent Authorization Letter | Cover Letter(s) | 2016-12-27 | PDF 131.6 KB |
| Confidentiality Letter | Cover Letter(s) | 2016-12-27 | PDF 35.1 KB |
| RF Exposure Info | RF Exposure Info | 2016-12-27 | PDF 379.1 KB |
| Block Diagram Metadata only | Block Diagram | PDF 117 KB | |
| Schematics 1 Metadata only | Schematics | PDF 197.9 KB | |
| Schematics 2 Metadata only | Schematics | PDF 271.6 KB | |
| Operational Description Metadata only | Operational Description | PDF 207.5 KB | |
| Module MPE Metadata only | SDR Software/Security Inf | PDF 14.5 KB |
Application Information
| Application ID | t6/vBhrbeHiuMIhcuBQn/Q== |
|---|---|
| Final Action Date | 2016-12-27 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0022043962 |
| Model | 1-21 |
| Frequency Range | 908.4-919.65 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Cellular Gateway |
| Responsible Party | Kevin R Jones, kevin.jones@ambiohealth.com , 9735680323 |
| Agent | Jeremy Jeremy Jeremy, SGS North America, jeremy.pickens@sgs.com , 770-570-1800 |
| Technical Contact | Jeremy Pickens, SGS North America, jeremy.pickens@sgs.com , 770-570-1800 |
| Non-Technical Contact | Jeremy Pickens, SGS North America, jeremy.pickens@sgs.com , 770-570-1800 |
| Test Firm | David Schramm, SGS North America, Inc., david.schramm@sgs.com , 973-461-7914 |
| TCB Email | uscts.tcb@sgs.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | Yes |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power Output listed is Conducted. Device is a 900MHz transmitter. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The device contains an approved CDMA modular which couldn’t be simultaneous transmission with the 900MHz transmitter. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| t6/vBhrbeHiuMIhcuBQn/Q== | 2016-12-27 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules |
|---|---|---|
| 908.4-919.65 MHz | 0.0050000 | 15C |
Grants
TCB Grant - Application t6/vBhrbeHiuMIhcuBQn/Q==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
SGS North America, Inc. 620 Old Peachtree Road NW Suite 100 Suwanee, GA 30024 |
Date of Grant: 12/27/2016 Application Dated: 12/27/2016 |
| Arrayent Health LLC d/b/a Ambio Health |
| Soundview Plaza Suite 700R |
| 1266 E Main St |
| Stamford, CT 06902 |
| Attention: Kevin Jones |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | Q4O-1-21 |
| Name of Grantee: | Arrayent Health LLC d/b/a Ambio Health |
| Equipment Class: | Digital Transmission System |
| Notes: | Cellular Gateway |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 908.4 - 919.65 | 0.005 |
| Power Output listed is Conducted. Device is a 900MHz transmitter. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The device contains an approved CDMA modular which couldn’t be simultaneous transmission with the 900MHz transmitter. |
EAS Grant - Application t6/vBhrbeHiuMIhcuBQn/Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Arrayent Health LLC d/b/a Ambio Health Soundview Plaza Suite 700R 1266 E Main StP.O. Box , Stamford, CT 06902 United States |
Date of Grant: 12/27/2016 Application Dated: 12/27/2016 |
| Attention: Kevin Jones |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | Q4O-1-21 |
| Name of Grantee: | Arrayent Health LLC d/b/a Ambio Health |
| Equipment Class: | Digital Transmission System |
| Notes: | Cellular Gateway |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 908.4 - 919.65 | 0.005 |
| Power Output listed is Conducted. Device is a 900MHz transmitter. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. End-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. The device contains an approved CDMA modular which couldn’t be simultaneous transmission with the 900MHz transmitter. |
| Mail To: |
