HVF601T Avail Wireless Dual Channel TENS... - FCC ID Q6ZHVF601T

FCC ID Q6ZHVF601T

03 (Short-Term Confidential) FCC Test Setup Photo

Avail Wireless Dual Channel TENS

by OMRON HEALTHCARE Co.,Ltd

Document preview loads when visible.

Document Details

FCC IDQ6ZHVF601T
Document ID3449376
Document TypeTest Setup Photos
Description03 (Short-Term Confidential) FCC Test Setup Photo
Document Title50080045 001_PM601_FCC 15.247_BLE
ApplicantOMRON HEALTHCARE Co.,Ltd
Equipment ClassAvail Wireless Dual Channel TENS
Product CodeHVF601T
Application IDw6vcg+hUZgi4AEK8KN6n8w==
Application PurposeOriginal Equipment
Application Date2017-07-04
Frequency Range2402-2480 MHz
FRN0021928791
Test FirmTUV Rheinland Taiwan Ltd.
Certified ByYoshihisa Maeda Senior Project Coordinator
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/31/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-07-04
Available2017-12-31
Created2017-07-04
Modified2017-07-04
Pages3
File TypeAdobe Acrobat PDF
File Size904051
File SHA-256f4e976ffb90668bc6c25dc6f0795bb57b953a0524663fdfc2b721a0c9e0503bf
PDF Metadata Authorkuos
PDF Metadata Producerkuos GPL Ghostscript 9.07
FCC.gov SourcesFCC.gov 3449376
