AAT IR REMOTE EXTENDER Teardown Internal Photos - FCC ID Q9NAAT
FCC ID Q9NAAT
INTERNAL PHOTOS
IR REMOTE EXTENDER
Document preview loads when visible.
Document Details
| FCC ID | Q9NAAT |
|---|---|
| Document ID | 342216 |
| Document Type | Internal Photos |
| Description | INTERNAL PHOTOS |
| Document Title | PSP PRINT |
| Applicant | Truett S. Thomas |
| Equipment Class | IR REMOTE EXTENDER |
| Product Code | AAT |
| Application ID | aHZGjcj2TTBB/ZYEreINHg== |
| Application Purpose | Original Equipment |
| Application Date | 2003-07-23 |
| Frequency Range | 433.5-434.5 MHz |
| FRN | 0009180134 |
| Test Firm | Product Safety Engineering, Inc. |
| Certified By | TRUETT THOMAS PROPRIETOR |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-07-23 |
| Available | 2003-07-23 |
| Created | 2003-07-14 |
| Modified | 2003-07-18 |
| Pages | 4 |
| File Type | Adobe Acrobat PDF |
| File Size | 608010 |
| File SHA-256 | f35966d8202ccdecf525caefea1c27c9016d0c0fe91c512a801634abc7c046ab |
| PDF Metadata Author | Owner |
| PDF Metadata Producer | Acrobat PDFWriter 5.0 for Windows NT Owner |
| FCC.gov Sources | FCC.gov 342216 |
