197 FM Wireless Microphone Schematics - FCC ID QCM197

FCC ID QCM197

schematics

FM Wireless Microphone

by Wellproof Manufactory Limited

Document preview loads when visible.

Document Details

FCC IDQCM197
Document ID242410
Document TypeSchematics
Descriptionschematics
ApplicantWellproof Manufactory Limited
Equipment ClassFM Wireless Microphone
Product Code197
Application IDnX6T5YSZ0xLCaYQPvFDBKA==
Application PurposeOriginal Equipment
Application Date2002-05-09
Frequency Range99.76-107 MHz
FRN0006928345
Test FirmSGS IECC Limited
Certified BySam Chiu Marketing Executive
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2002-05-13
Available2002-05-09
Created2002-05-07
Modified2002-05-07
Pages1
File TypeAdobe Acrobat PDF
File Size17499
File SHA-2561d06e169f4bbeaaef039949c8656fbf508fc1297468d7d78cb11cc0a25da1648
PDF Metadata ProducerAcrobat 5.0 Scan Plug-in for Windows Acrobat 5.0 Scan Plug-in for Windows
FCC.gov SourcesFCC.gov 242410
