FCC ID QDS-BRCM1076
Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCIE Mini Card
by Broadcom Corporation
Grantee Code: QDS Product Code: BRCM1076
Latest application date: 2016-01-21
Device Images
FCC ID Device Details
| FCC ID | QDS-BRCM1076 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | QDS |
| Product Code | BRCM1076 |
| Applicant Business | Broadcom Corporation 🇺🇸 |
| Related Domains |  broadcom.com |
| Equipment Class | Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCIE Mini Card |
| Test Firm | UL Verification Services Inc. (formerly UL CCS) |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-01-21 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-09-01 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-09-01 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-09-01 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-06-15 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-06-15 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-06-15 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-03-25 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-03-25 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-03-25 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-03-21 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-03-21 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-03-21 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-01-29 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-01-29 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-01-29 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-12-18 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2014-12-18 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-12-18 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2014-12-04 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-12-04 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-12-04 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-08-14 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-08-14 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2014-08-14 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-30 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-27 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-27 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-27 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-18 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-18 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2014-06-18 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2013-11-18 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2013-11-18 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2013-11-18 |
| 5180-5240 MHz | Original Equipment | 2013-07-25 |
| 2402-2480 MHz | Original Equipment | 2013-07-25 |
| 2402-2480 MHz | Original Equipment | 2013-07-25 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Manual 1 | Users Manual | 2016-02-14 | PDF 4.1 MB |
| Manual 2 | Users Manual | 2016-02-14 | PDF 338.5 KB |
| Manual 3 | Users Manual | 2016-02-14 | PDF 3 MB |
| User Manual1 | Users Manual | 2015-11-14 | PDF 155.3 KB |
| User Manual2 | Users Manual | 2015-11-14 | PDF 856.7 KB |
| User Manual3 | Users Manual | 2015-11-14 | PDF 540.5 KB |
| User Manual | Users Manual | 2015-10-23 | PDF 5.1 MB |
| User Manual Regulatory | Users Manual | 2015-10-23 | PDF 95.8 KB |
| Manual | Users Manual | 2015-09-21 | PDF 5.1 MB |
| Regulatory Notice | Users Manual | 2015-09-21 | PDF 95.8 KB |
| User Manual Regulatory Notice | Users Manual | 2015-09-18 | PDF 95.8 KB |
| User manual | Users Manual | 2015-07-28 | PDF 4.7 MB |
| Manual 1 | Users Manual | 2015-06-16 | PDF 4 MB |
| Manual 2 | Users Manual | 2015-06-16 | PDF 2 MB |
| Regulatory Notice | Users Manual | 2015-01-31 | PDF 127.5 KB |
| User Manual | Users Manual | 2015-01-31 | PDF 5.3 MB |
| User Manual1 | Users Manual | 2014-12-12 | PDF 273.1 KB |
| User Manual2 | Users Manual | 2014-12-12 | PDF 123.8 KB |
| User Manual3 | Users Manual | 2014-12-12 | PDF 5.2 MB |
| OEM installation Guide | Users Manual | 2014-11-17 | PDF 110.8 KB |
| BCM94352Z User Manual Revised 0617 | Users Manual | 2014-08-21 | PDF 89.5 KB |
| User Manual | Users Manual | 2014-08-21 | PDF 5.4 MB |
| user manual 02 | Users Manual | 2014-08-21 | PDF 118.3 KB |
| Internal Photos | Internal Photos | 2016-02-14 | PDF 899.3 KB |
| Internal Photo | Internal Photos | 2015-11-14 | PDF 1.5 MB |
| Photos Internal | Internal Photos | 2015-10-23 | PDF 827.9 KB |
| Internal Photos | Internal Photos | 2015-09-21 | PDF 822.3 KB |
| Internal Photos | Internal Photos | 2015-07-28 | PDF 1.5 MB |
| Internal Photos | Internal Photos | 2015-06-16 | PDF 654.3 KB |
| Internal Photos | Internal Photos | 2015-01-31 | PDF 203 KB |
| Internal Photo | Internal Photos | 2014-12-12 | PDF 205.2 KB |
| BCM94352Z Internal Photo | Internal Photos | 2014-08-21 | PDF 3.4 MB |
| Internal Photos | Internal Photos | 2014-08-21 | PDF 152.5 KB |
| External Photos | External Photos | 2016-02-14 | PDF 765.9 KB |
| External Photo | External Photos | 2015-11-14 | PDF 4.3 MB |
| Photos External | External Photos | 2015-10-23 | PDF 767.9 KB |
| External Photos | External Photos | 2015-09-21 | PDF 739.4 KB |
| External Photos | External Photos | 2015-07-28 | PDF 2.2 MB |
| External Photos | External Photos | 2015-06-16 | PDF 108.4 KB |
| External Photos | External Photos | 2015-01-31 | PDF 997.2 KB |
| External Photo | External Photos | 2014-12-12 | PDF 114.4 KB |
| BCM94352Z External Photo | External Photos | 2014-08-21 | PDF 870.4 KB |
| External Photos | External Photos | 2014-08-21 | PDF 959.6 KB |
| Label | ID Label/Location Info | 2015-09-01 | PDF 43.7 KB |
| Label Location | ID Label/Location Info | 2015-09-01 | PDF 1.6 MB |
| Host Label | ID Label/Location Info | 2015-06-15 | PDF 66.9 KB |
| Host Label Location | ID Label/Location Info | 2015-06-15 | PDF 162.6 KB |
| Host Lael Location | ID Label/Location Info | 2015-06-15 | PDF 162.6 KB |
| Host Location | ID Label/Location Info | 2015-06-15 | PDF 162.6 KB |
| Module Label and location | ID Label/Location Info | 2015-06-15 | PDF 70.2 KB |
| Label | ID Label/Location Info | 2015-03-25 | PDF 780.1 KB |
| ID Label | ID Label/Location Info | 2015-01-29 | PDF 352.7 KB |
| Label Location | ID Label/Location Info | 2015-01-29 | PDF 1.1 MB |
| Label & Location | ID Label/Location Info | 2014-12-18 | PDF 1.2 MB |
| Label and Location | ID Label/Location Info | 2014-12-04 | PDF 148.5 KB |
| label | ID Label/Location Info | 2014-08-14 | PDF 466.8 KB |
| BCM94352Z Label Sample & Location | ID Label/Location Info | 2014-06-18 | PDF 122.3 KB |
| Setup Photos | Test Setup Photos | 2016-02-14 | PDF 78.5 KB |
| 15U22567-E1V3 FCC Setup Photos UNII WLAN_C2PC_5.8 Band | Test Setup Photos | 2016-01-21 | PDF 671.9 KB |
| Test Setup photo | Test Setup Photos | 2015-11-14 | PDF 106 KB |
| Photo Test Setup WLAN B4 | Test Setup Photos | 2015-10-23 | PDF 365.7 KB |
| Photos SAR | Test Setup Photos | 2015-10-23 | PDF 572 KB |
| Photos Test Setup BT4.0 | Test Setup Photos | 2015-10-23 | PDF 322.3 KB |
| Photos Test Setup WLAN | Test Setup Photos | 2015-10-23 | PDF 483.3 KB |
| BLE Setup Photos | Test Setup Photos | 2015-09-21 | PDF 189.6 KB |
| BT Report Setup Photos | Test Setup Photos | 2015-09-21 | PDF 190 KB |
| DTS Setup Photos | Test Setup Photos | 2015-09-21 | PDF 189.8 KB |
| SAR Report Photos | Test Setup Photos | 2015-09-21 | PDF 638.8 KB |
| UNII B1-B3 Setup Photos | Test Setup Photos | 2015-09-21 | PDF 189.9 KB |
| UNII B4 Setup Photos | Test Setup Photos | 2015-09-21 | PDF 189.8 KB |
| Photos Test Setup BT | Test Setup Photos | 2015-09-18 | PDF 379.3 KB |
| Photos Test Setup NII B1-3 | Test Setup Photos | 2015-09-18 | PDF 663.1 KB |
| Photos Test Setup NII B4 Metadata only | Test Setup Photos | 2015-09-18 | PDF 365.7 KB |
| Photos Test Setup SAR | Test Setup Photos | 2015-09-18 | PDF 572 KB |
| Test Setup Photos | Test Setup Photos | 2015-07-28 | PDF 2.4 MB |
| SAR Setup Photos | Test Setup Photos | 2015-06-16 | PDF 394.7 KB |
| Test Setup Photos | Test Setup Photos | 2015-01-31 | PDF 99.8 KB |
| DTS WLAN Report_Photos | Test Setup Photos | 2014-12-26 | PDF 268.6 KB |
| Test Setup Photo | Test Setup Photos | 2014-12-12 | PDF 556.1 KB |
| SAR Set-up Photos | Test Setup Photos | 2014-11-17 | PDF 183.7 KB |
| BCM94352Z SAR Setup Photo | Test Setup Photos | 2014-08-21 | PDF 962.5 KB |
| SAR SETUP PHOTOS | Test Setup Photos | 2014-08-21 | PDF 189.1 KB |
| 15U22567-E1V3 FCC Report UNII WLAN_C2PC_5.8 Band | Test Report | 2016-01-21 | PDF 3.2 MB |
| SAR Test Report Part1 | RF Exposure Info | 2015-06-15 | PDF 1.3 MB |
| SAR Test Report Part2 | RF Exposure Info | 2015-06-15 | PDF 373.7 KB |
| SAR Test Report Part3 | RF Exposure Info | 2015-06-15 | PDF 183.1 KB |
| SAR Test Report Part4 | RF Exposure Info | 2015-06-15 | PDF 1.1 MB |
| BLE Report | Test Report | 2015-03-25 | PDF 919.7 KB |
| BT Report | Test Report | 2015-03-25 | PDF 1.4 MB |
| DTS Report | Test Report | 2015-03-25 | PDF 2 MB |
| UNII B1-B3 Report | Test Report | 2015-03-25 | PDF 3.1 MB |
| UNII B4 Report | Test Report | 2015-03-25 | PDF 1.2 MB |
| Test Report BT | Test Report | 2015-03-21 | PDF 853.5 KB |
| Test Report DTS BT4.0 | Test Report | 2015-03-21 | PDF 663.9 KB |
| Test Report DTS WLAN | Test Report | 2015-03-21 | PDF 1.1 MB |
| Test Report NII B1-B3 | Test Report | 2015-03-21 | PDF 1.7 MB |
| Test Report WLAN B4 | Test Report | 2015-03-21 | PDF 767.5 KB |
| SAR test report | RF Exposure Info | 2015-01-29 | PDF 1.2 MB |
| DTS WLAN Report | Test Report | 2014-06-30 | PDF 2.2 MB |
| FCC SAR Test Report | RF Exposure Info | 2014-06-18 | PDF 1.1 MB |
| SAR Test Report Metadata only | RF Exposure Info | 2014-06-18 | PDF 1.1 MB |
| Attestation Letter | Cover Letter(s) | 2014-08-14 | PDF 46.1 KB |
| FCC Class II permissive change letter | Attestation Statements | 2014-06-18 | PDF 26.4 KB |
| FCC DoC letter | Attestation Statements | 2014-06-18 | PDF 11.1 KB |
| BCM94352Z FCC C2PC (to new FCC UNII rule) updated | Cover Letter(s) | 2016-01-21 | PDF 25 KB |
| BCM94352Z FCC C2PC confidentiality request Jan 2016 | Cover Letter(s) | 2016-01-21 | PDF 246.3 KB |
| FCC Agent Authorization Letter (UL) Sept 2015 | Cover Letter(s) | 2016-01-21 | PDF 537.4 KB |
| FCC Class II Change Letter_BCM94352Z | Cover Letter(s) | 2015-09-01 | PDF 34.7 KB |
| FCC confidentiality request letter BCM94352Z | Cover Letter(s) | 2015-09-01 | PDF 58.1 KB |
| LOA BCM94352Z FCC, IC C2PC | Cover Letter(s) | 2015-09-01 | PDF 24.2 KB |
| LOA Lenovo for BCM94352Z, BCM943162ZP | Cover Letter(s) | 2015-09-01 | PDF 198.2 KB |
| C2PC Letter | Cover Letter(s) | 2015-06-15 | PDF 94.3 KB |
| Confidentiality Letter Rev | Cover Letter(s) | 2015-06-15 | PDF 79 KB |
| Confidentiality letter Metadata only | Cover Letter(s) | 2015-06-15 | PDF 74.8 KB |
| Label Justification Letter | Cover Letter(s) | 2015-06-15 | PDF 112.2 KB |
| POA Letter | Cover Letter(s) | 2015-06-15 | PDF 105.8 KB |
| Agent Authorization Letter | Cover Letter(s) | 2015-03-25 | PDF 394.3 KB |
| C2PC Letter | Cover Letter(s) | 2015-03-25 | PDF 232.9 KB |
| Confidentiality Letter | Cover Letter(s) | 2015-03-25 | PDF 270.9 KB |
| Agent Letter | Cover Letter(s) | 2015-03-21 | PDF 583.6 KB |
| C2PC Letter | Cover Letter(s) | 2015-03-21 | PDF 39.5 KB |
| Confidentiality Letter | Cover Letter(s) | 2015-03-21 | PDF 269.3 KB |
| C2PC | Cover Letter(s) | 2015-01-29 | PDF 28.9 KB |
| LOA | Cover Letter(s) | 2015-01-29 | PDF 21.7 KB |
| LOA Lenovo | Cover Letter(s) | 2015-01-29 | PDF 49.3 KB |
| RSE justification | Cover Letter(s) | 2015-01-29 | PDF 51.8 KB |
| conf. request | Cover Letter(s) | 2015-01-29 | PDF 259.9 KB |
| Authorization | Cover Letter(s) | 2014-12-18 | PDF 112.9 KB |
| Authorization Letter | Cover Letter(s) | 2014-12-18 | PDF 112.9 KB |
| C2PC Change letter | Cover Letter(s) | 2014-12-18 | PDF 93.8 KB |
| C2PC Cover Letter | Cover Letter(s) | 2014-12-18 | PDF 93.8 KB |
| Confidentiality | Cover Letter(s) | 2014-12-18 | PDF 39.9 KB |
| Agent Authoriation | Cover Letter(s) | 2014-12-04 | PDF 19.7 KB |
| Agent Authorization | Cover Letter(s) | 2014-12-04 | PDF 19.7 KB |
| C2PC Cover Letter | Cover Letter(s) | 2014-12-04 | PDF 24.1 KB |
| Confidentiality | Cover Letter(s) | 2014-12-04 | PDF 13 KB |
| C2PC | Cover Letter(s) | 2014-08-14 | PDF 1.6 MB |
| LOA | Cover Letter(s) | 2014-08-14 | PDF 22.4 KB |
| confidentiality request | Cover Letter(s) | 2014-08-14 | PDF 25.2 KB |
| C2PC letter | Cover Letter(s) | 2014-06-30 | PDF 20.5 KB |
| Confidentiality request letter | Cover Letter(s) | 2014-06-30 | PDF 31 KB |
| LOA | Cover Letter(s) | 2014-06-30 | PDF 19.1 KB |
| C2PC letter | Cover Letter(s) | 2014-06-27 | PDF 1.6 MB |
| conf. request | Cover Letter(s) | 2014-06-27 | PDF 48.7 KB |
| Authorisation letter | Cover Letter(s) | 2014-06-18 | PDF 22.4 KB |
| FCC Confidentiality Template | Cover Letter(s) | 2014-06-18 | PDF 33.4 KB |
| FCC+IC SAR NO photo | RF Exposure Info | 2015-09-01 | PDF 627.1 KB |
| SAR APPENDIX C DASY CALIBRATION CERTIFICATE | RF Exposure Info | 2015-09-01 | PDF 3.1 MB |
| SAR Appendix D Plots of SAR Test Result | RF Exposure Info | 2015-09-01 | PDF 247.1 KB |
| SAR Report | RF Exposure Info | 2015-03-25 | PDF 1.3 MB |
| SAR attachment 1 | RF Exposure Info | 2015-03-25 | PDF 696.9 KB |
| SAR attachment 2 | RF Exposure Info | 2015-03-25 | PDF 410.7 KB |
| SAR attachment 3 | RF Exposure Info | 2015-03-25 | PDF 1.6 MB |
| SAR attachment 4 | RF Exposure Info | 2015-03-25 | PDF 1.1 MB |
| SAR attachment 5 | RF Exposure Info | 2015-03-25 | PDF 178.3 KB |
| SAR attachment 6 | RF Exposure Info | 2015-03-25 | PDF 1.8 MB |
| SAR attachment 7 | RF Exposure Info | 2015-03-25 | PDF 1.4 MB |
| SAR attachment 8 | RF Exposure Info | 2015-03-25 | PDF 1.4 MB |
| SAR Cal DAE | RF Exposure Info | 2015-03-21 | PDF 896.9 KB |
| SAR Cal DAE4 | RF Exposure Info | 2015-03-21 | PDF 896.9 KB |
| SAR Cal Dipole 2.4G | RF Exposure Info | 2015-03-21 | PDF 1.4 MB |
| SAR Cal Dipole 5G | RF Exposure Info | 2015-03-21 | PDF 1.4 MB |
| SAR Cal Probe | RF Exposure Info | 2015-03-21 | PDF 2.7 MB |
| SAR Plots 2.4G | RF Exposure Info | 2015-03-21 | PDF 464.3 KB |
| SAR Plots 5G | RF Exposure Info | 2015-03-21 | PDF 1.5 MB |
| SAR Plots System Check | RF Exposure Info | 2015-03-21 | PDF 328.4 KB |
| SAR Report | RF Exposure Info | 2015-03-21 | PDF 1.3 MB |
| SAR System Performance Plots | RF Exposure Info | 2015-03-21 | PDF 328.4 KB |
| SAR Equipment Calibration | RF Exposure Info | 2015-01-29 | PDF 4.9 MB |
| SAR Appendix 1 | RF Exposure Info | 2014-12-18 | PDF 477.7 KB |
| SAR Appendix 2 | RF Exposure Info | 2014-12-18 | PDF 517.2 KB |
| SAR Appendix 3 | RF Exposure Info | 2014-12-18 | PDF 2 MB |
| SAR Appendix 4 | RF Exposure Info | 2014-12-18 | PDF 2.7 MB |
| SAR Appendix 5 | RF Exposure Info | 2014-12-18 | PDF 896.9 KB |
| SAR Appendix 6 | RF Exposure Info | 2014-12-18 | PDF 1.4 MB |
| SAR Appendix 7 | RF Exposure Info | 2014-12-18 | PDF 2.7 MB |
| SAR Report | RF Exposure Info | 2014-12-18 | PDF 1.4 MB |
| SAR appendix 5 | RF Exposure Info | 2014-12-18 | PDF 896.9 KB |
| SAR appendix 6 | RF Exposure Info | 2014-12-18 | PDF 1.4 MB |
| SAR Report1 | RF Exposure Info | 2014-12-04 | PDF 1.3 MB |
| SAR report2 | RF Exposure Info | 2014-12-04 | PDF 1.1 MB |
| SAR report3 | RF Exposure Info | 2014-12-04 | PDF 456 KB |
| SAR report4 | RF Exposure Info | 2014-12-04 | PDF 3.4 MB |
| SAR report5 | RF Exposure Info | 2014-12-04 | PDF 1.1 MB |
| SAR report6 | RF Exposure Info | 2014-12-04 | PDF 1.8 MB |
| SAR report7 | RF Exposure Info | 2014-12-04 | PDF 1.4 MB |
| SAR report8 | RF Exposure Info | 2014-12-04 | PDF 4.4 MB |
| Appendix E output power | RF Exposure Info | 2014-08-14 | PDF 558.8 KB |
| SAR Report | RF Exposure Info | 2014-08-14 | PDF 4.8 MB |
| SAR Report_test plots | RF Exposure Info | 2014-08-14 | PDF 1.6 MB |
| RF EXPOSURE | RF Exposure Info | 2014-06-30 | PDF 267.3 KB |
| Appendix E output power | RF Exposure Info | 2014-06-27 | PDF 472.2 KB |
| SAR report | RF Exposure Info | 2014-06-27 | PDF 3.5 MB |
| SAR test plots | RF Exposure Info | 2014-06-27 | PDF 957.7 KB |
| SAR Attachmemts 19.1--19.4 Metadata only | RF Exposure Info | 2014-06-18 | PDF 5 MB |
| SAR Attachmemts 19.5--19.8 Metadata only | RF Exposure Info | 2014-06-18 | PDF 4.4 MB |
Application Information
| Application ID | zRsrUzaiAoBZQ8ZGsy0wOw== |
|---|---|
| Final Action Date | 2016-01-21 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007091952 |
| Model | BRCM1076 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCIE Mini Card |
| Responsible Party | Anne Liang, Manager, Compliance Engineering, aliang@broadcom.com , 4089225890 |
| Test Firm | Jay Kogoma, UL Verification Services Inc. (formerly UL CCS), jay.kogoma@ul.com  , 510-319-4135 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II permissive change to show compliance with new UNII rules. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. For mobile configuration, the antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. For portable configuration, the approval is valid to allow installation with a minimum 10mm antenna-to-enclosure separation distance in tablets and 5mm antenna to user separation distance in the keyboard section of notebook/laptop PCs with the antennas documented in this filing. Use of other antennas is subject to FCC Permissive Change procedures which may require additional filing for a C2PC. The highest reported SAR is 0.36 W/kg. OEM integrators must be provided with antenna installation instructions. OEM integrators and end users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| zRsrUzaiAoBZQ8ZGsy0wOw== | 2016-01-21 | Class II permissive change or modification of presently authorized equipment |
| kZPLMHUKw4TN/zPutM6X3g== | 2015-09-01 | Class II permissive change or modification of presently authorized equipment |
| gWK4EEYXicuMQnkZFAKhiQ== | 2015-09-01 | Class II permissive change or modification of presently authorized equipment |
| GzypBnbBr87Wz7/anseBJQ== | 2015-09-01 | Class II permissive change or modification of presently authorized equipment |
| ycJgGYggPc2dCFGkeNlBkA== | 2015-06-15 | Class II permissive change or modification of presently authorized equipment |
| GWJbl/oT7k6a5rguKH62+g== | 2015-06-15 | Class II permissive change or modification of presently authorized equipment |
| G69J2cJIasZoRShT5txzaA== | 2015-06-15 | Class II permissive change or modification of presently authorized equipment |
| R5xuC7DC54TKAfXK3phIAw== | 2015-03-25 | Class II permissive change or modification of presently authorized equipment |
| CJtK/YB07EhBH/iYGwb2LA== | 2015-03-25 | Class II permissive change or modification of presently authorized equipment |
| 791DM4Ael+Fm17TvaB9jmg== | 2015-03-25 | Class II permissive change or modification of presently authorized equipment |
| wKeWs3CxuzOsVpAMSkikaQ== | 2015-03-21 | Class II permissive change or modification of presently authorized equipment |
| bUpxHrax0IMUnYd049KhRA== | 2015-03-21 | Class II permissive change or modification of presently authorized equipment |
| aRnBUKJ/DR27wjud6sUB2A== | 2015-03-21 | Class II permissive change or modification of presently authorized equipment |
| zltScM2QnkD17EwbuaFr6w== | 2015-01-29 | Class II permissive change or modification of presently authorized equipment |
| qnjeOxay1pwfQYQJQWXBxQ== | 2015-01-29 | Class II permissive change or modification of presently authorized equipment |
| msOoGXKvJ0FFoYMjwzAxpA== | 2015-01-29 | Class II permissive change or modification of presently authorized equipment |
| dUZ+xFHnmAmaQ/e0697vzQ== | 2014-12-18 | Class II permissive change or modification of presently authorized equipment |
| KmHXdjrsOga7Pl7G9q92FQ== | 2014-12-18 | Class II permissive change or modification of presently authorized equipment |
| /2MHJwxex74Zk/CxGOGiQQ== | 2014-12-18 | Class II permissive change or modification of presently authorized equipment |
| kzbEdA+a+EsyNBCni5mWAA== | 2014-12-04 | Class II permissive change or modification of presently authorized equipment |
| ccXMuInLEy9MQOAO938Ebw== | 2014-12-04 | Class II permissive change or modification of presently authorized equipment |
| OWaXWeIrWMDf+Dw2O8cZ1w== | 2014-12-04 | Class II permissive change or modification of presently authorized equipment |
| qcg/ZUGskdIU0skZ50xpSQ== | 2014-08-14 | Class II permissive change or modification of presently authorized equipment |
| QBO1dR0ApDH7R5K24yFHxQ== | 2014-08-14 | Class II permissive change or modification of presently authorized equipment |
| 6n8dh6hz37yQbKugQhScqQ== | 2014-08-14 | Class II permissive change or modification of presently authorized equipment |
| H7YEiDk7V1x+KI4d60HkrA== | 2014-06-30 | Class II permissive change or modification of presently authorized equipment |
| lPEtIatraEFCRzNQtkHI8Q== | 2014-06-27 | Class II permissive change or modification of presently authorized equipment |
| PqG7dZroirdjYf/EnSAP9w== | 2014-06-27 | Class II permissive change or modification of presently authorized equipment |
| 6RaK7rGjP23e+hvsKeb5LA== | 2014-06-27 | Class II permissive change or modification of presently authorized equipment |
| ZLEC8KW2G/GVSjkzf5FJlA== | 2014-06-18 | Class II permissive change or modification of presently authorized equipment |
| 4iEl1J+BLuxC6RXdPvt58g== | 2014-06-18 | Class II permissive change or modification of presently authorized equipment |
| +Y5s0dpcXFfSVru8Dw23DQ== | 2014-06-18 | Class II permissive change or modification of presently authorized equipment |
| RuWVbxnr9eMX2hCl8BG7NA== | 2013-11-18 | Class II permissive change or modification of presently authorized equipment |
| IJ9kApqXRNa44x4lIh8NTg== | 2013-11-18 | Class II permissive change or modification of presently authorized equipment |
| /db/zUZWh5zGoSQzVMFmNQ== | 2013-11-18 | Class II permissive change or modification of presently authorized equipment |
| ZfyLriD5O1rq1CuEvPPdLw== | 2013-07-31 | Original Equipment |
| u2j7J1JSOGQInacCXyWhbg== | 2013-07-25 | Original Equipment |
| IKanqv/yWXRZuq2ijfVZwA== | 2013-07-25 | Original Equipment |
| G9FWNjwknqdwRJje3h4vuA== | 2013-07-25 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules | Grant Notes |
|---|---|---|---|
| 2402-2480 MHz | 0.001 | 15C | CC |
| 2402-2480 MHz | 0.0050000 | 15C | CC |
| 2402-2480 MHz | 0.001 | 15C | CC, MO |
| 2412-2462 MHz | 0.172 | 15C | CC, MO |
| 5180-5240 MHz | 0.049 | 15E | CC, MO |
| 5180-5240 MHz | 0.049 | 15E | 38, CC, MO |
| 5260-5320 MHz | 0.218 | 15E | CC, MO, ND |
| 5260-5320 MHz | 0.218 | 15E | CC, MO |
| 5260-5320 MHz | 0.218 | 15E | 38, CC, MO, ND |
| 5500-5720 MHz | 0.206 | 15E | CC, MO, ND |
| 5500-5720 MHz | 0.206 | 15E | CC, MO |
| 5500-5720 MHz | 0.206 | 15E | 38, CC, MO, ND |
| 5510-5710 MHz | 0.217 | 15E | CC, MO, ND |
| 5510-5710 MHz | 0.217 | 15E | CC, MO |
| 5510-5710 MHz | 0.217 | 15E | 38, CC, MO, ND |
| 5745-5825 MHz | 0.214 | 15C | CC, MO |
Grants
TCB Grant - Application zRsrUzaiAoBZQ8ZGsy0wOw==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 01/21/2016 Application Dated: 01/21/2016 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCIE Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| 38 CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| 38 CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.197 |
| Class II permissive change to show compliance with new UNII rules. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. For mobile configuration, the antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. For portable configuration, the approval is valid to allow installation with a minimum 10mm antenna-to-enclosure separation distance in tablets and 5mm antenna to user separation distance in the keyboard section of notebook/laptop PCs with the antennas documented in this filing. Use of other antennas is subject to FCC Permissive Change procedures which may require additional filing for a C2PC. The highest reported SAR is 0.36 W/kg. OEM integrators must be provided with antenna installation instructions. OEM integrators and end users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application zRsrUzaiAoBZQ8ZGsy0wOw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 01/21/2016 Application Dated: 01/21/2016 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCIE Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| 38 CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| 38 CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| 38 CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.197 |
| Class II permissive change to show compliance with new UNII rules. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. For mobile configuration, the antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. For portable configuration, the approval is valid to allow installation with a minimum 10mm antenna-to-enclosure separation distance in tablets and 5mm antenna to user separation distance in the keyboard section of notebook/laptop PCs with the antennas documented in this filing. Use of other antennas is subject to FCC Permissive Change procedures which may require additional filing for a C2PC. The highest reported SAR is 0.36 W/kg. OEM integrators must be provided with antenna installation instructions. OEM integrators and end users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 01/29/2015 Application Dated: 01/29/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Yoga 3 14 Haydn) that described in this filing. The highest reported SAR values is 1.51 W/Kg. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.51 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multitransmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application zltScM2QnkD17EwbuaFr6w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 01/29/2015 Application Dated: 01/29/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Yoga 3 14 Haydn) that described in this filing. The highest reported SAR values is 1.51 W/Kg. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.51 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multitransmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
TUV SUD BABT Octagon House, Concorde Way, Segensworth North, Fareham, PO15 5RL United Kingdom |
Date of Grant: 06/18/2014 Application Dated: 06/18/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. C2PC. This device and associated FCC ID label are to be installed in the specific portable platform Lenvov Regulatory with model number: Lenovo Yoga 2 13 shown in this filing only by OEM or OEM integrators – user installation is prohibited. Instructions on the installation and/or removal of this module may not be provided to the end user. Only the antenna(s) documented in this filing, installed in the manner specified, can be used with this device. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application ZLEC8KW2G/GVSjkzf5FJlA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 06/18/2014 Application Dated: 06/18/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. C2PC. This device and associated FCC ID label are to be installed in the specific portable platform Lenvov Regulatory with model number: Lenovo Yoga 2 13 shown in this filing only by OEM or OEM integrators – user installation is prohibited. Instructions on the installation and/or removal of this module may not be provided to the end user. Only the antenna(s) documented in this filing, installed in the manner specified, can be used with this device. This device and its antenna(s) must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/31/2013 Application Dated: 07/25/2013 |
| Broadcom Corporation |
| 190 Mathilda Place |
| Sunnyvale, CA 94086 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
EAS Grant - Application ZfyLriD5O1rq1CuEvPPdLw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 190 Mathilda Place Sunnyvale, CA 94086 United States |
Date of Grant: 07/31/2013 Application Dated: 07/25/2013 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15B | - |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 06/15/2015 Application Dated: 05/18/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11 a/b/g/n/ac WLAN+ Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II Permissive Change to allow portable configuration in the Portable Computer(Dell Model: P20T) with reduced power as described in this filing. Output power is conducted. It must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application ycJgGYggPc2dCFGkeNlBkA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 06/15/2015 Application Dated: 05/18/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11 a/b/g/n/ac WLAN+ Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II Permissive Change to allow portable configuration in the Portable Computer(Dell Model: P20T) with reduced power as described in this filing. Output power is conducted. It must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/21/2015 Application Dated: 03/21/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.001 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Flex 3-1470, Flex 3-1435, Flex 3-1475) with reduced power as described in this filing. The highest reported SAR value for this filing is 1.06 W/kg. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.51 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application wKeWs3CxuzOsVpAMSkikaQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 03/21/2015 Application Dated: 03/21/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.001 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Flex 3-1470, Flex 3-1435, Flex 3-1475) with reduced power as described in this filing. The highest reported SAR value for this filing is 1.06 W/kg. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.51 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/25/2013 Application Dated: 07/25/2013 |
| Broadcom Corporation |
| 190 Mathilda Place |
| Sunnyvale, CA 94086 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application u2j7J1JSOGQInacCXyWhbg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 190 Mathilda Place Sunnyvale, CA 94086 United States |
Date of Grant: 07/25/2013 Application Dated: 07/25/2013 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 11/18/2013 Application Dated: 11/18/2013 |
| Broadcom Corporation |
| 190 Mathilda Place |
| Sunnyvale, CA 94086 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II permissive change filing to allow installation with a minimum 10mm antenna-to-enclosure separation distance in tablets and 5mm antenna to user separation distance in the keyboard section of notebook/laptop PCs with the antennas documented in this filing. Use of other antennas is subject to FCC Permissive Change procedures which may require additional filing for a C2PC. Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application RuWVbxnr9eMX2hCl8BG7NA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 190 Mathilda Place Sunnyvale, CA 94086 United States |
Date of Grant: 11/18/2013 Application Dated: 11/18/2013 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II permissive change filing to allow installation with a minimum 10mm antenna-to-enclosure separation distance in tablets and 5mm antenna to user separation distance in the keyboard section of notebook/laptop PCs with the antennas documented in this filing. Use of other antennas is subject to FCC Permissive Change procedures which may require additional filing for a C2PC. Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/25/2015 Application Dated: 03/25/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2402.0 - 2480.0 | 0.001 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Flex 3-1570, Flex 3-1535) at reduced powers described in this filing. The highest reported SAR values for body and simultaneous exposure conditions are 1.37 W/kg and 1.37 W/kg respectively. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.51 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application R5xuC7DC54TKAfXK3phIAw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 03/25/2015 Application Dated: 03/25/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2402.0 - 2480.0 | 0.001 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Flex 3-1570, Flex 3-1535) at reduced powers described in this filing. The highest reported SAR values for body and simultaneous exposure conditions are 1.37 W/kg and 1.37 W/kg respectively. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.51 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 01/29/2015 Application Dated: 01/29/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Yoga 3 14 Haydn) that described in this filing. Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application qnjeOxay1pwfQYQJQWXBxQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 01/29/2015 Application Dated: 01/29/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Yoga 3 14 Haydn) that described in this filing. Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 08/14/2014 Application Dated: 08/14/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.001 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 |
| Class II permissive change to allow use in portable host Lenovo YOGA 3 Pro-1370 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.28 W/Kg and 1.41 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multitransmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application qcg/ZUGskdIU0skZ50xpSQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 08/14/2014 Application Dated: 08/14/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.001 | ||
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 |
| Class II permissive change to allow use in portable host Lenovo YOGA 3 Pro-1370 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.28 W/Kg and 1.41 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multitransmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 08/14/2014 Application Dated: 08/14/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II permissive change to allow use in portable host Lenovo YOGA 3 Pro-1370 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application QBO1dR0ApDH7R5K24yFHxQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 08/14/2014 Application Dated: 08/14/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II permissive change to allow use in portable host Lenovo YOGA 3 Pro-1370 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. Output power is conducted. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 06/27/2014 Application Dated: 06/27/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Class II permissive change to allow use in portable host Lenovo Yoga 2 Pro with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.14 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multitransmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application PqG7dZroirdjYf/EnSAP9w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 06/27/2014 Application Dated: 06/27/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Class II permissive change to allow use in portable host Lenovo Yoga 2 Pro with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.14 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multitransmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 12/04/2014 Application Dated: 12/04/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11 a/b/g/n WLAN+Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Class II permissive change to allow use in portable host Lenovo Yoga 3 11 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.12 W/Kg and the highest reported SAR value across all filings under this FCC ID is 1.39 W/kg. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application OWaXWeIrWMDf+Dw2O8cZ1w==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 12/04/2014 Application Dated: 12/04/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11 a/b/g/n WLAN+Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Class II permissive change to allow use in portable host Lenovo Yoga 3 11 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.12 W/Kg and the highest reported SAR value across all filings under this FCC ID is 1.39 W/kg. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 01/29/2015 Application Dated: 01/29/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Yoga 3 14 Haydn) that described in this filing. The highest reported SAR values is 1.02 W/Kg. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.39 W/Kg and 1.53 W/Kg respectively. Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application msOoGXKvJ0FFoYMjwzAxpA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 01/29/2015 Application Dated: 01/29/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II Permissive Change to allow portable configuration in the specific laptop/notebook host (Lenovo Yoga 3 14 Haydn) that described in this filing. The highest reported SAR values is 1.02 W/Kg. The highest reported SAR values for body and simultaneous exposure conditions across all filings under this equipment code and FCC ID are 1.39 W/Kg and 1.53 W/Kg respectively. Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 06/27/2014 Application Dated: 06/27/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II permissive change to allow use in portable host Lenovo Yoga 2 Pro with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.14 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application lPEtIatraEFCRzNQtkHI8Q==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 06/27/2014 Application Dated: 06/27/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II permissive change to allow use in portable host Lenovo Yoga 2 Pro with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body and simultaneous transmission exposure conditions are 1.14 W/Kg and 1.58 W/Kg respectively. Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 09/01/2015 Application Dated: 08/31/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II Permissive Change to allow portable configuration in the Portable Computer (Lenovo ideapad Y700-15ACZ, Lenovo ideapad Y700-15ISK, Lenovo ideapad Y700 Touch-15ISK) with reduced power as described in this filing. Output power is conducted. It must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application kZPLMHUKw4TN/zPutM6X3g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 09/01/2015 Application Dated: 08/31/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.005 |
| Class II Permissive Change to allow portable configuration in the Portable Computer (Lenovo ideapad Y700-15ACZ, Lenovo ideapad Y700-15ISK, Lenovo ideapad Y700 Touch-15ISK) with reduced power as described in this filing. Output power is conducted. It must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 12/04/2014 Application Dated: 12/04/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 a/b/g/n WLAN+Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II permissive change to allow use in portable host Lenovo Yoga 3 11 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body exposure condition is 1.09 W/Kg and the highest reported SAR value across all filings under this FCC ID is 1.39 W/kg. Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application kzbEdA+a+EsyNBCni5mWAA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 12/04/2014 Application Dated: 12/04/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11 a/b/g/n WLAN+Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II permissive change to allow use in portable host Lenovo Yoga 3 11 with the antennas documented in this filing. Output power of module is reduced for this host due to the SAR and emission requirement. The highest reported SAR values for body exposure condition is 1.09 W/Kg and the highest reported SAR value across all filings under this FCC ID is 1.39 W/kg. Power output listed is conducted. Operations in the 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in all bands. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 12/18/2014 Application Dated: 12/18/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II Permissive Change to allow installation into portable hosts Lenovo Edge 15 and Flex 2 Pro-15 with power reduction for 802.11 operating modes and using the antennas as described in this filing. The highest reported SAR in this filing is 1.29 W/Kg. The highest reported SAR value across all filings under this FCC ID is 1.39 W/kg. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
EAS Grant - Application KmHXdjrsOga7Pl7G9q92FQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 12/18/2014 Application Dated: 12/18/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | 802.11a/b/g/n WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.049 | ||
| CC MO ND | 15E | 5260.0 - 5320.0 | 0.218 | ||
| CC MO ND | 15E | 5500.0 - 5720.0 | 0.206 | ||
| CC MO ND | 15E | 5510.0 - 5710.0 | 0.217 |
| Class II Permissive Change to allow installation into portable hosts Lenovo Edge 15 and Flex 2 Pro-15 with power reduction for 802.11 operating modes and using the antennas as described in this filing. The highest reported SAR in this filing is 1.29 W/Kg. The highest reported SAR value across all filings under this FCC ID is 1.39 W/kg. Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| ND: | This UNII device complies with the Transmit Power Control (TPC) and Dynamic Frequency Selection (DFS) requirements in Section 15.407(h). |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/25/2013 Application Dated: 07/25/2013 |
| Broadcom Corporation |
| 190 Mathilda Place |
| Sunnyvale, CA 94086 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application IKanqv/yWXRZuq2ijfVZwA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 190 Mathilda Place Sunnyvale, CA 94086 United States |
Date of Grant: 07/25/2013 Application Dated: 07/25/2013 |
| Attention: Daniel Lawless , Director of Engineering, System Operations |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1076 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | 802.11a/b/g/n/ac WLAN + Bluetooth PCI-E Mini Card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15C | 2412.0 - 2462.0 | 0.172 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.214 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.001 |
| Power output listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20 MHz, 40 MHz and 80 MHz bandwidths in the 5 GHz band. 802.11 operations in the 2.4 GHz band support only 20 MHz bandwidths. The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators must be provided with antenna installation instructions. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
