FCC ID QDS-BRCM1084
Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card
by Broadcom Corporation
Grantee Code: QDS Product Code: BRCM1084
Latest application date: 2016-02-01
Device Images
FCC ID Device Details
| FCC ID | QDS-BRCM1084 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | QDS |
| Product Code | BRCM1084 |
| Applicant Business | Broadcom Corporation 🇺🇸 |
| Related Domains |  broadcom.com |
| Equipment Class | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Test Firm | SPORTON International Inc. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-01 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-01 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-02-01 |
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2015-08-31 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-08-31 |
| 2402-2480 MHz | Class II permissive change or modification of presently authorized equipment | 2015-08-31 |
| 5180-5240 MHz | Original Equipment | 2014-07-06 |
| 2402-2480 MHz | Original Equipment | 2014-07-06 |
| 2402-2480 MHz | Original Equipment | 2014-07-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| UM | Users Manual | 2016-02-01 | PDF 793.8 KB |
| OEM installation Guide | Users Manual | 2015-01-02 | PDF 109.8 KB |
| User Manual | Users Manual | 2015-01-02 | PDF 571.4 KB |
| Internal Photos_20150729_v1 - QDS-BRCM1084_IN-PHOTO | Internal Photos | 2016-02-24 | PDF 306 KB |
| QDS-BRCM1084_IN-PHOTO | Internal Photos | 2016-02-24 | PDF 306 KB |
| Internal Photos | Internal Photos | 2015-01-02 | PDF 340.7 KB |
| External Photos_20150729_v1 - QDS-BRCM1084_EX-PHOTO | External Photos | 2016-02-24 | PDF 339.3 KB |
| QDS-BRCM1084_EX-PHOTO | External Photos | 2016-02-24 | PDF 339.3 KB |
| External Photos | External Photos | 2015-01-02 | PDF 294 KB |
| ID Label | ID Label/Location Info | 2014-07-06 | PDF 74.1 KB |
| QDS-BRCM1084_TEST PHOTOS | Test Setup Photos | 2016-02-24 | PDF 376.1 KB |
| Test Setup Photos_20150729_v1 - QDS-BRCM1084_TEST PHOTOS | Test Setup Photos | 2016-02-24 | PDF 376.1 KB |
| Test Setup Photos | Test Report | 2016-02-01 | PDF 105.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-02-01 | PDF 105.8 KB |
| DFS Test Photo | Test Setup Photos | 2015-01-02 | PDF 111.7 KB |
| Test Setup Photos_JBP | Test Setup Photos | 2015-01-02 | PDF 345.1 KB |
| Test Setup Photos_NII | Test Setup Photos | 2015-01-02 | PDF 416 KB |
| Test Setup Photos_SAR | Test Setup Photos | 2015-01-02 | PDF 151 KB |
| RF Report | Test Report | 2016-02-01 | PDF 2.5 MB |
| QDS-BRCM1084_RF Report_5G B1-B3 | Test Report | 2015-08-31 | PDF 1.5 MB |
| QDS-BRCM1084_RF Report_5G B1-B3_Radiated Band-edge | Test Report | 2015-08-31 | PDF 567.9 KB |
| QDS-BRCM1084_RF Report_5G B1-B3_Radiated Band-edge_verified | Test Report | 2015-08-31 | PDF 109.4 KB |
| QDS-BRCM1084_RF Report_5G B1-B3_Radiated emissions | Test Report | 2015-08-31 | PDF 968.9 KB |
| QDS-BRCM1084_Radiated Emission Co-Location Report | Test Report | 2015-08-31 | PDF 132.5 KB |
| Test Report_20150729_v1 - QDS-BRCM1084_RF Report_BT2.1+EDR | Test Report | 2015-08-31 | PDF 1.1 MB |
| Test Report_20150729_v1 - QDS-BRCM1084_RF Report_BT4.0 | Test Report | 2015-08-31 | PDF 642.2 KB |
| Test Report_20150729_v1 - QDS-BRCM1084_Radiated Emission Co-Location Report | Test Report | 2015-08-31 | PDF 132.5 KB |
| Test Report_20150812_v2 - QDS-BRCM1084_RF Report_2.4G_5G B4 | Test Report | 2015-08-31 | PDF 5.6 MB |
| 20dB bandwidth | Test Report | 2014-07-06 | PDF 309.5 KB |
| DFS Test Report | Test Report | 2014-07-06 | PDF 2.6 MB |
| Radiated Emission Co-Location | Test Report | 2014-07-06 | PDF 139.5 KB |
| SAR Test Report | RF Exposure Info | 2014-07-06 | PDF 1.7 MB |
| Test Reoprt_DTS_Bluetooth 4.0 | Test Report | 2014-07-06 | PDF 1.4 MB |
| Test Report_DSS | Test Report | 2014-07-06 | PDF 2.2 MB |
| Test Report_DTS_WLAN | Test Report | 2014-07-06 | PDF 3.1 MB |
| Test Report_JBP | Test Report | 2014-07-06 | PDF 481.6 KB |
| Test Report_NII | Test Report | 2014-07-06 | PDF 1.8 MB |
| C2PC Letter | Cover Letter(s) | 2016-02-01 | PDF 65.9 KB |
| Confidentiality request | Cover Letter(s) | 2016-02-01 | PDF 68 KB |
| Confidentiality request letter | Cover Letter(s) | 2016-02-01 | PDF 68 KB |
| POA | Cover Letter(s) | 2016-02-01 | PDF 26.2 KB |
| Cover Letters_20150729_v1 - QDS-BRCM1084_FCC C2PC letter | Cover Letter(s) | 2015-08-31 | PDF 108.9 KB |
| Cover Letters_20150729_v1 - QDS-BRCM1084_POA | Cover Letter(s) | 2015-08-31 | PDF 88.7 KB |
| Cover Letters_20150812_v2 - QDS-BRCM1084_Confidential Letter | Cover Letter(s) | 2015-08-31 | PDF 263 KB |
| QDS-BRCM1084_FCC C2PC letter | Cover Letter(s) | 2015-08-31 | PDF 108.9 KB |
| QDS-BRCM1084_POA | Cover Letter(s) | 2015-08-31 | PDF 88.7 KB |
| Confidential Letter | Cover Letter(s) | 2014-07-06 | PDF 52.4 KB |
| Declaration | Cover Letter(s) | 2014-07-06 | PDF 27.2 KB |
| Power of Attorney | Cover Letter(s) | 2014-07-06 | PDF 24.4 KB |
| Request for modular approval | Cover Letter(s) | 2014-07-06 | PDF 144.9 KB |
| Human Exposure | RF Exposure Info | 2016-02-01 | PDF 132.5 KB |
| QDS-BRCM1084_Human Exposure | RF Exposure Info | 2015-08-31 | PDF 135.2 KB |
| Calibration | RF Exposure Info | 2014-07-06 | PDF 5.3 MB |
| Plots of SAR | RF Exposure Info | 2014-07-06 | PDF 2.7 MB |
| Plots of System | RF Exposure Info | 2014-07-06 | PDF 1.4 MB |
| Block Diagram Metadata only | Block Diagram | PDF 10.5 KB | |
| Block Diagrams Metadata only | Block Diagram | PDF 10.5 KB | |
| Schematics Metadata only | Schematics | PDF 97.3 KB | |
| Antenna Report Metadata only | Operational Description | PDF 852.2 KB | |
| Attestations_20150729_v1 - QDS-BRCM1084_Antenna Spec (1) Metadata only | Operational Description | PDF 230 KB | |
| Attestations_20150729_v1 - QDS-BRCM1084_Antenna Spec (2) Metadata only | Operational Description | PDF 547.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 171 KB | |
| Operational Description Metadata only | Operational Description | PDF 128.2 KB | |
| Operational Description_20150729_v1 - QDS-BRCM1084_Operational_description Metadata only | Operational Description | PDF 235.8 KB | |
| QDS-BRCM1084_Antenna Spec (1) Metadata only | Operational Description | PDF 230 KB | |
| QDS-BRCM1084_Antenna Spec (2) Metadata only | Operational Description | PDF 547.9 KB | |
| QDS-BRCM1084_Antenna Spec1 Metadata only | Operational Description | PDF 547.9 KB | |
| QDS-BRCM1084_Operational_description Metadata only | Operational Description | PDF 235.8 KB | |
| Software Security Requirements Metadata only | Operational Description | PDF 48.2 KB |
Application Information
| Application ID | ob/8wcJol1M5xiQaEQEgVw== |
|---|---|
| Final Action Date | 2016-02-01 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0007091952 |
| Model | BRCM1084 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Responsible Party | Anne Liang, Manager, Compliance Engineering, aliang@broadcom.com , 4089225890 |
| Test Firm | Sharon Jiang, SPORTON International Inc., sharonjiang@sporton.com.tw  , 886-3-656-9065 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.80 W/kg. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| ob/8wcJol1M5xiQaEQEgVw== | 2016-02-01 | Class II permissive change or modification of presently authorized equipment |
| IyltAiX0vOSMrkI6GGO4RA== | 2016-02-01 | Class II permissive change or modification of presently authorized equipment |
| 5twGnA/RekVTQVJur/tNHQ== | 2016-02-01 | Class II permissive change or modification of presently authorized equipment |
| i+RX/JbmxSz5nTPUybRlVQ== | 2015-08-31 | Class II permissive change or modification of presently authorized equipment |
| h7gJFYuUDv4iMNkVv5EZxA== | 2015-08-31 | Class II permissive change or modification of presently authorized equipment |
| RRBRiK6rfY1aS4VuFkVUPA== | 2015-08-31 | Class II permissive change or modification of presently authorized equipment |
| pOT9Jve8qYp9lnHr/UNqMA== | 2014-07-06 | Original Equipment |
| pGsx+o+Nim0KikDWfArNWg== | 2014-07-06 | Original Equipment |
| kxhKPNVRUkQacMm1MVvJ/g== | 2014-07-06 | Original Equipment |
| ae87RgXa36RincbqnVMapg== | 2014-07-06 | Original Equipment |
Equipment Authorization
| Frequency | Output | Rules | Grant Notes |
|---|---|---|---|
| 15B | CC | ||
| 2402-2480 MHz | 0.0013000 | 15C | CC |
| 2402-2480 MHz | 0.0005 | 15C | CC |
| 2412-2472 MHz | 0.1845 | 15C | CC, MO |
| 5180-5240 MHz | 0.0406 | 15E | 38, CC, MO |
| 5180-5240 MHz | 0.0406 | 15E | CC, MO |
| 5260-5320 MHz | 0.1416 | 15E | 38, CC, MO |
| 5260-5320 MHz | 0.1416 | 15E | CC, MO |
| 5500-5700 MHz | 0.1178 | 15E | 38, CC, MO |
| 5500-5700 MHz | 0.1178 | 15E | CC, MO |
| 5745-5825 MHz | 0.104 | 15C | CC, MO |
| 5745-5825 MHz | 0.2449 | 15E | 38, CC, MO |
Grants
TCB Grant - Application RRBRiK6rfY1aS4VuFkVUPA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 08/31/2015 Application Dated: 08/28/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0013 |
| Class II Permission Change Application add new dipole antennas. Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application RRBRiK6rfY1aS4VuFkVUPA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 08/31/2015 Application Dated: 08/28/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0013 |
| Class II Permission Change Application add new dipole antennas. Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.0406 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.1416 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.1178 |
| Modular approval. Output power listed is conducted. Operations in 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.81 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application pOT9Jve8qYp9lnHr/UNqMA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.0406 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.1416 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.1178 |
| Modular approval. Output power listed is conducted. Operations in 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.81 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0005 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.1845 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.104 |
| Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.80 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application pGsx+o+Nim0KikDWfArNWg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0005 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.1845 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.104 |
| Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.80 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0005 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.1845 |
| Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.80 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application ob/8wcJol1M5xiQaEQEgVw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0005 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.1845 |
| Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.80 W/kg. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15B | - |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application kxhKPNVRUkQacMm1MVvJ/g==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Class B Computing Device Peripheral |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15B | - |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0013 |
| Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application IyltAiX0vOSMrkI6GGO4RA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0013 |
| Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 08/31/2015 Application Dated: 08/28/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.0406 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.1416 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.1178 |
| Class II Permission Change Application add new dipole antennas. Modular approval. Output power listed is conducted. Operations in 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application i+RX/JbmxSz5nTPUybRlVQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 08/31/2015 Application Dated: 08/28/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC MO | 15E | 5180.0 - 5240.0 | 0.0406 | ||
| CC MO | 15E | 5260.0 - 5320.0 | 0.1416 | ||
| CC MO | 15E | 5500.0 - 5700.0 | 0.1178 |
| Class II Permission Change Application add new dipole antennas. Modular approval. Output power listed is conducted. Operations in 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 08/31/2015 Application Dated: 08/28/2015 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0005 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.1845 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.104 |
| Class II Permission Change Application add new dipole antennas. Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application h7gJFYuUDv4iMNkVv5EZxA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 08/31/2015 Application Dated: 08/28/2015 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Digital Transmission System |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0005 | ||
| CC MO | 15C | 2412.0 - 2472.0 | 0.1845 | ||
| CC MO | 15C | 5745.0 - 5825.0 | 0.104 |
| Class II Permission Change Application add new dipole antennas. Modular approval. Output power listed is conducted. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. 2402-2480MHz is for Bluetooth LE. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0013 |
| Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
EAS Grant - Application ae87RgXa36RincbqnVMapg==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 07/06/2014 Application Dated: 07/06/2014 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.0013 |
| Modular approval. Output power listed is conducted. This module may only be installed by the OEM or an OEM integrator. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures or as described in the filing. OEM integrators and end users must be provided with specific operating instructions for satisfying RF exposure compliance requirements. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| Mail To: | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Broadcom Corporation |
| 270 Innovation Drive |
| San Jose, CA 95134 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.0406 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.1416 | ||
| 38 CC MO | 15E | 5500.0 - 5700.0 | 0.1178 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.2449 |
| Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. Operations in 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.81 W/kg. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
EAS Grant - Application 5twGnA/RekVTQVJur/tNHQ==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Broadcom Corporation 270 Innovation Drive San Jose, CA 95134 United States |
Date of Grant: 02/01/2016 Application Dated: 02/01/2016 |
| Attention: Anne Liang , Manager, Compliance Engineering |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QDS-BRCM1084 |
| Name of Grantee: | Broadcom Corporation |
| Equipment Class: | Unlicensed National Information Infrastructure TX |
| Notes: | Broadcom 802.11a/b/g/n WLAN+ Bluetooth PCI-E NGFF2230 card |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 38 CC MO | 15E | 5180.0 - 5240.0 | 0.0406 | ||
| 38 CC MO | 15E | 5260.0 - 5320.0 | 0.1416 | ||
| 38 CC MO | 15E | 5500.0 - 5700.0 | 0.1178 | ||
| 38 CC MO | 15E | 5745.0 - 5825.0 | 0.2449 |
| Class II permissive change filing for show compliance with New U-NII rule per FCC ET docket No. 13-49 for both the mobile and portable category as documented in this filing. Modular approval. Output power listed is conducted. Operations in 5.15-5.25 GHz band are for indoor use only. Device operates with specific antennas in MIMO configurations as described in this filing. This device supports 20MHz and 40MHz bandwidths for 802.11n. Approval is valid when antennas used for this transmitter are installed to provide a minimum antenna separation distance of 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators and end-users must be provided with transmitter operation conditions for satisfying RF exposure compliance. The highest reported SAR for body and simultaneous transmission use conditions are 0.78 W/kg, and 0.81 W/kg. |
| 38: | This device has shown compliance, in all grant-listed U-NII sub-bands, with the new rules for U-NII devices adopted under Docket No. 13-49 and may be marketed, manufactured or imported after the June 1, 2016 transition deadline. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
| MO: | This Multiple Input Multiple Output (MIMO) device was evaluated for multiple transmitted signals as indicated in the filing. |
| Mail To: |
