13001TX27 RC Toy Transmitter Schematics - FCC ID QE813001TX27

FCC ID QE813001TX27

schematics

RC Toy Transmitter

by Interactive Toy Concepts Limited

Document preview loads when visible.

Document Details

FCC IDQE813001TX27
Document ID274154
Document TypeSchematics
Descriptionschematics
Document Title(148)
ApplicantInteractive Toy Concepts Limited
Equipment ClassRC Toy Transmitter
Product Code13001TX27
Application IDrIZQqIu1lxV3zQTRmvJiIA==
Application PurposeOriginal Equipment
Application Date2002-10-02
Frequency Range27.145 MHz
FRN0007208176
Test FirmHong Kong Standards & Testing Cen.
Certified ByChris Harvey Director, EMC Laboratory
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2002-10-02
Available2002-10-02
Created2002-09-25
Modified2002-09-25
Pages1
File TypeAdobe Acrobat PDF
File Size39354
File SHA-2562bf75b9c65ac00852b68eeab4a43de82eb25971e5de947c5ac806d511ebad514
PDF Metadata Authorcee3
PDF Metadata ProducerSeptember 25, 2002 (148) Acrobat PDFWriter 4.0 for Windows
FCC.gov SourcesFCC.gov 274154
