23401TX49 RC Toy Teardown Internal Photos - FCC ID QE823401TX49

FCC ID QE823401TX49

Internal Photo

RC Toy

by Interactive Toy Concepts Limited

Document preview loads when visible.

Document Details

FCC IDQE823401TX49
Document ID354638
Document TypeInternal Photos
DescriptionInternal Photo
Document TitleIphoto1.PDF
ApplicantInteractive Toy Concepts Limited
Equipment ClassRC Toy
Product Code23401TX49
Application IDSBjeKP3OBiWwCgpnwmim9g==
Application PurposeOriginal Equipment
Application Date2003-09-09
Frequency Range49.86 MHz
FRN0007208176
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2003-09-09
Available2003-09-09
Created2003-08-02
Modified2003-08-02
Pages2
File TypeAdobe Acrobat PDF
File Size288580
File SHA-256e14d855c9be0dd9e667f3fe58238ece95352066ab9a90bf58c8e1bd52e8cab3d
PDF Metadata Authorilo
PDF Metadata ProducerMicrosoft Word Acrobat PDFWriter 4.0 for Windows
FCC.gov SourcesFCC.gov 354638
