MDM49T MDM Patriot Flames (Model: 10704)... - FCC ID QEAMDM49T
FCC ID QEAMDM49T
PCB TX SIL Bottom Layout
MDM Patriot Flames (Model: 10704)
Document preview loads when visible.
Document Details
| FCC ID | QEAMDM49T |
|---|---|
| Document ID | 688048 |
| Document Type | Schematics |
| Description | PCB TX SIL Bottom Layout |
| Document Title | CAM output |
| Applicant | Kid Galaxy Inc. |
| Equipment Class | MDM Patriot Flames (Model: 10704) |
| Product Code | MDM49T |
| Application ID | OZTG7R9U2mLHi/Op/GRstw== |
| Application Purpose | Original Equipment |
| Application Date | 2006-07-31 |
| Frequency Range | 49.85 MHz |
| FRN | 0007127632 |
| Test Firm | Hong Kong Standards and Testing Centre |
| Certified By | Marie Ann Confroy Quality and Certifications Administrator |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2006-07-31 |
| Available | 2006-07-31 |
| Created | 2006-07-07 |
| Modified | 2006-07-07 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 24784 |
| File SHA-256 | 71e4fe4dfb069f13133270d8d43375f8bb3532cef5a1e1ac2a3fb8ec9913d743 |
| PDF Metadata Author | ELEC201 |
| PDF Metadata Producer | pdfFactory Pro www.fineprint.com.cn pdfFactory Pro 2.27 (Windows 2000 Professional Chinese) |
| FCC.gov Sources | FCC.gov 688048 |
